4 MP Web Camera

  • High quality imaging with 2560 × 1440 resolution
  • Low distortion lens for reducing image distortion
  • Built-in dual-microphone with clear sound
  • USB Type-C interface, supporting USB 2.0 protocols
  • Plug-and-play, no need to install driver software
  • Support auto focus

View Less
View more

Available models:

DS-UC4

Specification

  • Camera
  • Image Sensor4 MP CMOS
  • Signal SystemPAL/NTSC
  • Frame RateMJPG： 2560 × 1440 @ 30 fps/25 fps 1920 × 1080 @ 60 fps/50 fps/30 fps/25 fps 1280 × 960 @ 60 fps/50 fps/30 fps/25 fps 1280 × 720 @ 60 fps/50 fps/30 fps/25 fps 640 × 480 @ 60 fps/50 fps/30 fps/25 fps 640 × 360 @ 30 fps/25 fps YUV2： 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30 fps 640 × 360 @ 30 fps
  • Resolution2560 (H) × 1440 (V)
  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Lens3.6 mm fixed focal lens
  • Field of Viewhorizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
  • Lens MountM8
  • Day & Night24/7 Color Imaging
  • Angle Adjustmentpan: 0° to 360°; tilt: 0° to 90°; rotation: 0°
  • Digital Zoom1.5 ×
  • Cable Length2 m
  • Lens
  • Depth of Field5 cm to ∞
  • Image
  • Wide Dynamic Range (WDR)Digital WDR
  • White BalanceAuto
  • Audio
  • Audio Sampling Rate16 kHz
  • Interface
  • Video OutputUSB 2.0
  • Operating SystemRecommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
  • Built-in Microphone2 built-in microphones, picking up sounds in the radius up to 5 meters
  • IndicatorWhite: Normally Working
  • General
  • Operating Conditions-10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
  • Power SupplyDC 5V ± 5% (USB)
  • Consumption2.5 W MAX
  • Dimension120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
  • WeightApprox. 147 g (0.32 lb.)
  • Accessory
  • Packing ListCamera × 1 USB Cable × 1 Quick Start Guide × 1
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Camera
Image Sensor
4 MP CMOS
Signal System
PAL/NTSC
Frame Rate
MJPG： 2560 × 1440 @ 30 fps/25 fps 1920 × 1080 @ 60 fps/50 fps/30 fps/25 fps 1280 × 960 @ 60 fps/50 fps/30 fps/25 fps 1280 × 720 @ 60 fps/50 fps/30 fps/25 fps 640 × 480 @ 60 fps/50 fps/30 fps/25 fps 640 × 360 @ 30 fps/25 fps YUV2： 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30 fps 640 × 360 @ 30 fps
Resolution
2560 (H) × 1440 (V)
Min. Illumination
0.1 Lux @ (F1.2, AGC ON)
Shutter Time
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Lens
3.6 mm fixed focal lens
Field of View
horizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
Lens Mount
M8
Day & Night
24/7 Color Imaging
Angle Adjustment
pan: 0° to 360°; tilt: 0° to 90°; rotation: 0°
Digital Zoom
1.5 ×
Cable Length
2 m
Lens
Depth of Field
5 cm to ∞
Wide Dynamic Range (WDR)
Digital WDR
White Balance
Auto
Audio
Audio Sampling Rate
16 kHz
Interface
Video Output
USB 2.0
Operating System
Recommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
Built-in Microphone
2 built-in microphones, picking up sounds in the radius up to 5 meters
Indicator
White: Normally Working
General
Operating Conditions
-10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
Power Supply
DC 5V ± 5% (USB)
Consumption
2.5 W MAX
Dimension
120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
Weight
Approx. 147 g (0.32 lb.)
Accessory
Packing List
Camera × 1 USB Cable × 1 Quick Start Guide × 1
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specification
Camera
  • Image Sensor4 MP CMOS
  • Signal SystemPAL/NTSC
  • Frame RateMJPG： 2560 × 1440 @ 30 fps/25 fps 1920 × 1080 @ 60 fps/50 fps/30 fps/25 fps 1280 × 960 @ 60 fps/50 fps/30 fps/25 fps 1280 × 720 @ 60 fps/50 fps/30 fps/25 fps 640 × 480 @ 60 fps/50 fps/30 fps/25 fps 640 × 360 @ 30 fps/25 fps YUV2： 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30 fps 640 × 360 @ 30 fps
  • Resolution2560 (H) × 1440 (V)
  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
  • Lens3.6 mm fixed focal lens
  • Field of Viewhorizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
  • Lens MountM8
  • Day & Night24/7 Color Imaging
  • Angle Adjustmentpan: 0° to 360°; tilt: 0° to 90°; rotation: 0°
  • Digital Zoom1.5 ×
  • Cable Length2 m
Lens
  • Depth of Field5 cm to ∞
  • Wide Dynamic Range (WDR)Digital WDR
  • White BalanceAuto
Audio
  • Audio Sampling Rate16 kHz
Interface
  • Video OutputUSB 2.0
  • Operating SystemRecommended systems Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version) Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS
  • Built-in Microphone2 built-in microphones, picking up sounds in the radius up to 5 meters
  • IndicatorWhite: Normally Working
General
  • Operating Conditions-10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
  • Power SupplyDC 5V ± 5% (USB)
  • Consumption2.5 W MAX
  • Dimension120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
  • WeightApprox. 147 g (0.32 lb.)
Accessory
  • Packing ListCamera × 1 USB Cable × 1 Quick Start Guide × 1
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
