2MP ColorVu Varifocal Dome Camera

High quality imaging with 2 MP, 1920 × 1080 resolution
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm to 12 mm motorized varifocal lens
Up to 60 m IR distance for bright night imaging
High quality audio with audio over coaxial cable, built-in mic
Water and dust resistant (IP67) and vandal resistant (IK10)

View Less

Available models:

DS-2CE50D8T-VPITSZE(2.8-12mm)(Europe)

DS-2CE50D8T-VPITSZE

Specification
Resources
Accessories

Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.0005 Lux @ (F1.28, AGC ON)
Day & NightICR
Angle AdjustmentPan: 0 to 355°, Tilt: 0 to 75°, Rotation: 0 to 355°
Signal SystemPAL/NTSC
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Lens
Lens Type2.8 mm to 12 mm motorized
Focal Length & FOVHorizontal FOV: 106° to 32°, vertical FOV: 56° to 18°, diagonal FOV: 127° to 37°
Lens MountΦ14

Illuminator
Supplement Light TypeIR
Supplement Light RangeIR: Up to 60 m
Smart Supplement LightYes

Image Parameters SwitchSTD/HIGH-SAT
Image Settings Brightness, Contrast, Sharpness, Anti-banding, AGC
Frame RateTVI: 1080p @30 fps, 1080p @25 fps
Day/Night ModeAuto
Wide Dynamic Range (WDR)≥130 dB
Image EnhancementWDR, BLC, HLC, Global, HLS
Privacy Mask4 programmable privacy masks
Noise Reduction3D DNR
White Balance Auto, Manual

Interface
Video Output1 HD analog output
Built-in MicrophoneYes

Event
Motion Detection4 programmable motion areas

General
Power12 VDC±25%/PoC.at, Max. 7.4 W *You are recommended to use one power adapter to supply the power for one camera.
MaterialMetal
DimensionØ121.5 mm × 97.6 mm (Ø4.78" × 3.84")
WeightApprox. 570 g (1.26 lb.)
Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
CommunicationHIKVISION-C
LanguageEnglish

Approval
ProtectionIP67, IK10

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Min. Illumination

0.0005 Lux @ (F1.28, AGC ON)

Day & Night

ICR

Angle Adjustment

Pan: 0 to 355°, Tilt: 0 to 75°, Rotation: 0 to 355°

Signal System

PAL/NTSC

Shutter Time

PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Lens

Lens Type

2.8 mm to 12 mm motorized

Focal Length & FOV

Horizontal FOV: 106° to 32°, vertical FOV: 56° to 18°, diagonal FOV: 127° to 37°

Lens Mount

Φ14

Illuminator

Supplement Light Type

Supplement Light Range

IR: Up to 60 m

Smart Supplement Light

Yes


Image Parameters Switch

STD/HIGH-SAT

Image Settings

Brightness, Contrast, Sharpness, Anti-banding, AGC

Frame Rate

TVI: 1080p @30 fps, 1080p @25 fps

Day/Night Mode

Auto

Wide Dynamic Range (WDR)

≥130 dB

Image Enhancement

WDR, BLC, HLC, Global, HLS

Privacy Mask

4 programmable privacy masks

Noise Reduction

3D DNR

White Balance

Auto, Manual

Interface

Video Output

1 HD analog output

Built-in Microphone

Yes

Event

Motion Detection

4 programmable motion areas

General

Power

12 VDC±25%/PoC.at, Max. 7.4 W *You are recommended to use one power adapter to supply the power for one camera.

Material

Metal

Dimension

Ø121.5 mm × 97.6 mm (Ø4.78" × 3.84")

Weight

Approx. 570 g (1.26 lb.)

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)

Communication

HIKVISION-C

Language

English

Approval

Protection

IP67, IK10
