2 MP Fixed Bullet PT Network Camera

  • High quality imaging with 2 MP resolution
  • Pan and tilt ability that enables the camera to capture larger and interested areas
  • Water and dust resistant (IP66)
  • EXIR 2.0, advanced infrared technology with long IR distance
  • Efficient H.265+ compression technology
  • Support Human and Vehicle Detection
View Less
View more

Available models:

DS-2CD1P23G2-I(2.8mm)
DS-2CD1P23G2-I(4mm)
Specification
  • Camera
  • Image Sensor 1/2.8" Progressive Scan CMOS
  • Max. Resolution 1920 × 1080
  • Min. Illumination Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
  • Shutter Time 1/3 s to 1/100,000 s
  • Day & Night IR cut filter
  • Angle Adjustment Pan: -100° to 100°,tilt: -20° to 45°
  • Lens
  • Lens Type Fixed focal lens, 2.8 and 4 mm optional
  • Focal Length & FOV 2.8 mm, horizontal FOV 109°, vertical FOV 60°, diagonal FOV 129° 4 mm, horizontal FOV 86°, vertical FOV 47°, diagonal FOV 103°
  • Lens Mount M12
  • Iris Type Fixed
  • Aperture Max. F2.0
  • DORI
  • DORI 2.8 mm: D: 40 m, O: 16 m, R: 8 m, I: 4 m 4 mm: D: 55 m, O: 21 m, R: 11 m, I: 5 m
  • Illuminator
  • Supplement Light Type IR
  • Supplement Light Range Up to 30 m
  • Smart Supplement Light Yes
  • IR Wavelength 850 nm
  • Video
  • Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate 32 Kbps to 8 Mbps
  • H.264 Type Baseline Profile/Main Profile/High Profile
  • H.265 Type Main Profile
  • Bit Rate Control CBR/VBR
  • Region of Interest (ROI) 1 fixed region for main stream
  • Audio
  • Audio Type -U: Mono sound
  • Environment Noise Filtering -U: Yes
  • Audio Sampling Rate<
