2 MP DarkFighter Varifocal Bullet Network Camera

  • High quality imaging with 2 MP resolution
  • Efficient H.265+ compression technology
  • Motorized varifocal lens for easy installation and monitoring
  • Excellent low-light performance with DarkFighter technology
  • Focus on human and vehicle targets classification based on deep learning
  • Clear imaging against strong back light due to 140 dB WDR technology
  • Audio and alarm interface available
  • Water and dust resistant (IP67) and vandal-resistant (IK10)

View Less
View more

Available models:

DS-2CD3B26G2T-IZHS(2.8-12mm)(C)
DS-2CD3B26G2T-IZHS(8-32mm)(C)
Especificación
  • Cámara
  • Sensor de imagen 1/1.8" Progressive Scan CMOS
  • Max. Resolución 1920 × 1080
  • Iluminación mínima Color: 0.0014 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR
  • Tiempo de obturación 1/3 s to 1/100,000 s
  • Día y Noche IR cut filter
  • Ajuste de ángulo Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
  • Lente
  • Lente Varifocal lens, motor-driven lens, 2.8 to 12 mm and 8 to 32 mm optional
  • Focal Length & FOV 2.8 to 12 mm: horizontal FOV 107° to 40°, vertical FOV 56° to 22°, diagonal FOV 130° to 46° 8 to 32 mm: horizontal FOV 43° to 15°, vertical FOV 23° to 9°, diagonal FOV 50° to 17°
  • Montura del lente Integrated
  • Iris Type P-iris
  • Apertura 2.8 to 12 mm: F1.4 8 to 32 mm: F1.6
  • DORI
  • DORI 2.8 to 12 mm: D: 61 m to 151 m, O: 24 m to 60 m, R: 12 m to 30 m, I: 6 m to 15 m 8 to 32 mm: D: 150 m to 400 m, O: 59 m to 158 m, R: 30 m to 80 m, I: 15 m to 40 m
  • Iluminador
  • Tipo de luz suplementaria IR
  • Rango de luz suplementaria 2.8 to 12 mm: up to 60 m 8 to 32 mm: up to 80 m
  • Luz de suplemento inteligente Yes
  • IR Wavelength 850 nm
  • Vídeo
  • Main stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
  • Sub-stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
  • Fourth Stream 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under certain settings.
  • Compresión de video Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG *Third stream and fourth stream are supported under certain settings.
  • Vídeo bitrate 32 Kbps to 8 Mbps
  • Tipo H.264 Baseline Profile/Main Profile/High Profile
  • Tipo H.265 Main Profile
  • Bit Rate Control CBR/VBR
  • Codificación de video escalable (SVC) H.264 and H.265 encoding
  • Región de interés (ROI) 5 fixed regions for main stream and sub-stream
  • Recorte objetivo Yes
  • Audio
  • Compresión de audio G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
  • Velocidad de bits de audio 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
  • Frecuencia de muestreo de audio 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Filtro de ruido ambiental Yes
  • Red
  • Protocolos TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP
  • Vista en vivo simultánea Up to 6 channels
  • API Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
  • Usuario/operador Up to 32 users. 3 user levels: administrator, operator and user
  • Seguridad Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
  • Almacenamiento en red MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • Cliente iVMS-4200, Hik-Connect, Hik-Central
  • Navegador web Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
  • Imagen
  • Interruptor de parámetros de imagen Yes
  • Configuración de imagen Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
  • Interruptor día/noche Day, Night, Auto, Schedule
  • Wide Dynamic Range (WDR) 140 dB
  • SNR ≥ 52 dB
  • Mejora de la imagen BLC, HLC, 3D DNR
  • Interfaz
  • Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
  • Audio 1 input (line in), two-core terminal block, max. input amplitude: 3.3 vpp, input impedance: 2.2 KΩ, interface type: non-equilibrium; 1 output (line out), two-core terminal block, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarma 3 inputs, 3 outputs (max. 24 VDC/24 VAC, 1 A)
  • RS-485 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • Reset Key Yes
  • Salida de alimentación 12 VDC, max. 100 mA
  • Evento
  • Evento Básico Motion detection (human and vehicle targets classification), video tampering alarm, exception
  • Evento inteligente Unattended baggage detection, object removal detection, scene change detection, audio exception detection
  • Linkage Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, audible warning
  • Deep Learning Function
  • Captura de la cara Yes
  • Protección perimetral Line crossing detection, intrusion detection, region entrance detection, region exiting detection
  • General
  • alimentación 12 VDC ± 25%, 1.08 A, max. 13 W, two-core terminal block 24 VAC ± 20%, 0.90 A, 50/60 Hz, max. 13 W PoE (802.3at, Class 4, 42.5 V to 57 V), 0.36 A to 0.27 A, max. 15 W
  • Dimensión Ø105 mm × 340.8 mm (Ø4.1" × 13.4")
  • Dimensión del paquete 385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1")
  • Approx. 1330 g (2.9 lb.)
  • Con peso del paquete Approx. 2231 g (4.9 lb.)
  • Condiciones de almacenaje -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Condiciones de inicio y funcionamiento -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Función general Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
  • Idioma del cliente web 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • Certificaciones
  • EMC FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
  • Seguridad UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
  • Ambiente CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
  • Protección IP67 (IEC 60529-2013), IK10 (IEC 62262:2002)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Especificación

Cámara
Sensor de imagen
1/1.8" Progressive Scan CMOS
Max. Resolución
1920 × 1080
Iluminación mínima
Color: 0.0014 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR
Tiempo de obturación
1/3 s to 1/100,000 s
Día y Noche
IR cut filter
Ajuste de ángulo
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lente
Lente
Varifocal lens, motor-driven lens, 2.8 to 12 mm and 8 to 32 mm optional
Focal Length & FOV
2.8 to 12 mm: horizontal FOV 107° to 40°, vertical FOV 56° to 22°, diagonal FOV 130° to 46° 8 to 32 mm: horizontal FOV 43° to 15°, vertical FOV 23° to 9°, diagonal FOV 50° to 17°
Montura del lente
Integrated
Iris Type
P-iris
Apertura
2.8 to 12 mm: F1.4 8 to 32 mm: F1.6
DORI
DORI
2.8 to 12 mm: D: 61 m to 151 m, O: 24 m to 60 m, R: 12 m to 30 m, I: 6 m to 15 m 8 to 32 mm: D: 150 m to 400 m, O: 59 m to 158 m, R: 30 m to 80 m, I: 15 m to 40 m
Iluminador
Tipo de luz suplementaria
IR
Rango de luz suplementaria
2.8 to 12 mm: up to 60 m 8 to 32 mm: up to 80 m
Luz de suplemento inteligente
Yes
IR Wavelength
850 nm
Vídeo
Main stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-stream
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Fourth Stream
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under certain settings.
Compresión de video
Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG *Third stream and fourth stream are supported under certain settings.
Vídeo bitrate
32 Kbps to 8 Mbps
Tipo H.264
Baseline Profile/Main Profile/High Profile
Tipo H.265
Main Profile
