Polymer 4MP 42x Anti-corrosion Speed Dome

1/1.8" progressive scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with DarkFighter technology
42× optical zoom and 16× digital zoom provide close up views over expansive areas
Expansive night view with up to 500 m IR distance
Water and dust resistant (IP67)
Anti-corrosion polymer enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras

View Less

Data Sheet

Available models:

DS-2DT8C442MXG-LWT

Especificación
Resources
Accesorios

Data Sheet

Cámara
Sensor de imagen1/1.8" progressive scan CMOS
Iluminación mínimaColor: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR
Velocidad de obturación1s to 1/30,000 s
Obturador lentoYes
Día y NocheIR cut filter
Zoom42x optical, 16x digital
Max. Resolución2560 × 1440

Lente
EnfoqueAuto, semi-auto, manual
Longitud focal6.0 mm to 252 mm
Velocidad del ZoomApprox. 5.4 s
FOVHorizontal field of view: 58.8° to 1.97° (wide-tele), Vertical field of view: 34.6° to 1.12° (wide-tele), Diagonal field of view: 67.1° to 2.28° (wide-tele)
AperturaMax. F1.2

Iluminador
Tipo de luz suplementariaHybrid
Rango de luz suplementariaIR Distance: up to 500 m White Light Distance: up to 100 m
Luz de suplemento inteligenteYes

PTZ
Rango de movimiento (pan)360°
Rango de movimiento (tilt)-20° to 90° (auto flip)
Velocidad de movimiento horizontal (pan)Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
Velocidad de vertical (tilt)Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
Proportional PanYes
Preajustes300
Escaneo de patrulla8 patrols, up to 32 presets for each patrol
Patrón de escaneo4 pattern scans, record time over 10 minutes for each scan
Memoria de apagadoYes
Acción del parquePreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
Posicionamiento 3DYes
Pantalla de estado de PTZYes
Congelación preestablecidaYes
Tarea programadaPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Vídeo
Main stream50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Compresión de vídeoMain stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG
Vídeo bitrate32 Kbps to 16384 Kbps
Tipo H.264Baseline Profile/Main Profile/High Profile
Tipo H.265Main Profile
Codificación de video escalable (SVC)H.264 and H.265 encoding
Región de interés (ROI)8 fixed regions for each stream

Audio
Compresión de audioG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC
Velocidad de bits de audio64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps~192 Kbps(MP2L2)/16 Kbps~64 Kbps(AAC)

Red
Almacenamiento en redNAS (NFS, SMB/ CIFS), ANR
ProtocolosIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets
APIISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T)
Vista en vivo simultáneaUp to 20 channels
Usuario/operadorUp to 32 users 3 user levels: administrator, operator, and user
SeguridadPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
ClienteHikCentral, iVMS-4200, Hik-Connect
Navegador webIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

AI Open Platform
Model SpecificationUp to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model)

Imagen
Interruptor día/nocheDay, night, auto, scheduled-switch
Mejora de la imagenBLC, HLC, 3D DNR
Wide Dynamic Range (WDR)120 dB
DesempañarOptical defog
Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
Exposición regionalYes
Enfoque regionalYes
Configuración de imagenSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Interruptor de parámetros de imagenYes
Máscara de privacidadUp to 24 masks, mosaic mask, mask color configurable, rectangle region
SNR≥ 52 dB

Interfaz
Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
Almacenamiento a bordoBuilt-in memory card slot, support microSD/microSDHC/microSDXC cards, up to 256 GB
Alarma7 inputs, 2 outputs
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
RS-485Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive

Evento
Evento BásicoAudio exception, motion detection, video tampering alarm, alarm input, alarm output, exception
Evento inteligenteLine crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection
Seguimiento inteligenteManual tracking, auto-tracking
Enlace de alarmaPreset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, NAS video recording, audible warning

Deep Learning Function
Protección perimetralLine crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

General
alimentación36 VDC ± 25%, max. 60 W,24 VAC ± 25%, max. 60 W
Operating ConditionTemperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
Idioma33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Limpiador de lenteYes
DimensiónØ 242 mm × 398.1 mm (Ø 9.53" × 15.67")
Approx. 6 kg (13.2 lb.)

Certificaciones
EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2019)
SeguridadUL (UL 62368-1) CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
AmbienteCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protección anticorrosivaNEMA 4X (NEMA 250-2018),C5
ProtecciónIP67 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Cámara

Sensor de imagen

1/1.8" progressive scan CMOS

Iluminación mínima

Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR

Velocidad de obturación

1s to 1/30,000 s

Obturador lento

Yes

Día y Noche

IR cut filter

Zoom

42x optical, 16x digital

Max. Resolución

2560 × 1440

Lente

Enfoque

Auto, semi-auto, manual

Longitud focal

6.0 mm to 252 mm

Velocidad del Zoom

Approx. 5.4 s

FOV

Horizontal field of view: 58.8° to 1.97° (wide-tele), Vertical field of view: 34.6° to 1.12° (wide-tele), Diagonal field of view: 67.1° to 2.28° (wide-tele)

Apertura

Max. F1.2

Iluminador

Tipo de luz suplementaria

Hybrid

Rango de luz suplementaria

IR Distance: up to 500 m White Light Distance: up to 100 m

Luz de suplemento inteligente

Yes

PTZ

Rango de movimiento (pan)

360°

Rango de movimiento (tilt)

-20° to 90° (auto flip)

Velocidad de movimiento horizontal (pan)

Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s

Velocidad de vertical (tilt)

Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s

Proportional Pan

Yes

Preajustes

300

Escaneo de patrulla

8 patrols, up to 32 presets for each patrol

Patrón de escaneo

4 pattern scans, record time over 10 minutes for each scan

Memoria de apagado

Yes

Acción del parque

Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan

Posicionamiento 3D

Yes

Pantalla de estado de PTZ

Yes

Congelación preestablecida

Yes

Tarea programada

Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Vídeo

Main stream

50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream

50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Compresión de vídeo

Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG

Vídeo bitrate

32 Kbps to 16384 Kbps

Tipo H.264

Baseline Profile/Main Profile/High Profile

Tipo H.265

Main Profile

Codificación de video escalable (SVC)

H.264 and H.265 encoding

Región de interés (ROI)

8 fixed regions for each stream

Audio

Compresión de audio

G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC

Velocidad de bits de audio

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps~192 Kbps(MP2L2)/16 Kbps~64 Kbps(AAC)

Red

Almacenamiento en red

NAS (NFS, SMB/ CIFS), ANR

Protocolos

IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets

API

ISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T)

Vista en vivo simultánea

Up to 20 channels

Usuario/operador

Up to 32 users 3 user levels: administrator, operator, and user

Seguridad

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)

Cliente

HikCentral, iVMS-4200, Hik-Connect

Navegador web

IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

AI Open Platform

Model Specification

Up to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model)

Imagen

Interruptor día/noche

Day, night, auto, scheduled-switch

Mejora de la imagen

BLC, HLC, 3D DNR

Wide Dynamic Range (WDR)

120 dB

Desempañar

Optical defog

Image Stabilization

EIS (Built-in gyroscope to improve EIS performance)

Exposición regional

Yes

Enfoque regional

Yes

Configuración de imagen

Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser

Interruptor de parámetros de imagen

Yes

Máscara de privacidad

Up to 24 masks, mosaic mask, mask color configurable, rectangle region

SNR

≥ 52 dB

Interfaz

Ethernet Interface

1 RJ45 10M/100M self-adaptive Ethernet port

Almacenamiento a bordo

Built-in memory card slot, support microSD/microSDHC/microSDXC cards, up to 256 GB

Alarma

7 inputs, 2 outputs

Audio

1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω

RS-485

Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive

Evento

Evento Básico

Audio exception, motion detection, video tampering alarm, alarm input, alarm output, exception

Evento inteligente

Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection

Seguimiento inteligente

Manual tracking, auto-tracking

Enlace de alarma

Preset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, NAS video recording, audible warning

Deep Learning Function

Protección perimetral

Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

General

alimentación

36 VDC ± 25%, max. 60 W,24 VAC ± 25%, max. 60 W

Operating Condition

Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%

Idioma

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Limpiador de lente

Yes

Dimensión

Ø 242 mm × 398.1 mm (Ø 9.53" × 15.67")

Approx. 6 kg (13.2 lb.)

Certificaciones

EMC

CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2019)

Seguridad

UL (UL 62368-1) CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);

Ambiente

CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protección anticorrosiva

NEMA 4X (NEMA 250-2018),C5

Protección

IP67 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
