TandemVu 8-inch Panoramic 4 MP 25X DarkFighter Network Speed Dome

Captures a large area and great details at the same time
High quality imaging with 4 MP resolution for both bullet channel and PTZ channel
24/7 colorful imaging and excellent low-light performance with DarkFighter technology
Bullet channel tilt adjustable from 7° to 17°
Secures an expansive area with 25 × optical zoom and 16 × digital zoom
Expansive night view with up to 30 m white light distance and 300 m IR distance
Supports deep learning functions
Water and dust resistant (IP67) and vandal resistant (IK10)

View Less

Ficha Técnica

Modelos disponibles:

DS-2SF8C425MXS-DL(24F0)(P3)

EOL

Especificación
Resources
Accesorios

Ficha Técnica

Cámara
Sensor de imagen[Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS
Iluminación mínima[Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light, [PTZ channel] Color: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON), 0 lux with IR
Velocidad de obturación1 s to 1/30000 s
Obturador lentoYes
Día y Noche[Bullet channel] Color, [PTZ channel] IR cut filter
Zoom[PTZ channel] 25 × optical, 16 × digital
Max. Resolución[Bullet channel] 3840 × 1080, [PTZ channel] 2560 × 1440

Lente
EnfoqueAuto,semi-auto,manual
Velocidad del Zoom[Bullet channel] No, [PTZ channel] approx. 4.8 s
Longitud focal[Bullet channel] 2.8 mm, [PTZ channel] 5.9 to 147.5 mm
FOV[Bullet channel] horizontal field of view: 190° ± 5°, vertical field of view: 50° ± 5°, diagonal field of view: 198° ± 5°, [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 68.5° to 3.5°
Apertura[Bullet channel] F1.0, [PTZ channel] F1.5

Iluminador
Rango de luz suplementaria[Bullet channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m
Luz de suplemento inteligenteYes

PTZ
Rango de movimiento (pan) [PTZ channel] 0° to 360°
Rango de movimiento (tilt)[Bullet channel] 7° to 17°, [PTZ channel] -20° to 90°
Velocidad de movimiento horizontal (pan)[PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s
Velocidad de vertical (tilt)[Bullet channel] tilt speed configurable,[PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
Proportional Pan[Bullet channel] No, [PTZ channel] Yes
Preajustes300
Escaneo de patrulla8 patrols, up to 32 presets for each patrol
Patrón de escaneo4 pattern scans, record time over 10 minutes for each scan
Memoria de apagadoYes
Acción del parquePreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan
Posicionamiento 3DYes
Pantalla de estado de PTZYes
Congelación preestablecidaYes
Tarea programadaPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output

Vídeo
Main stream[Bullet channel] 50 Hz: 25 fps (3840 × 1080), 60 Hz: 24 fps (3840 × 1080),[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream[Bullet channel] 50 Hz: 25 fps (1920 × 536), 60 Hz: 24 fps (1920 × 536),[PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream[Bullet channel] No,[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Compresión de vídeoMain stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Vídeo bitrate32 Kbps to 16 Mbps
Tipo H.264Baseline profile,Main profile,High profile
Tipo H.265Main profile
Codificación de video escalable (SVC)H.264 and H.265 encoding
Región de interés (ROI)8 fixed regions for each stream

Audio
Compresión de audioG.711,G.722.1,G.726,MP2L2,PCM,AAC
Velocidad de bits de audio32 to 192 Kbps (MP2L2),16 to 64 Kbps (AAC)
Frecuencia de muestreo de audio8 kHz,16 kHz,32 kHz,48 kHz
Filtro de ruido ambientalYes

Red
APIISUP,ISAPI,SDK,Open Network Video Interface (Profile S, Profile G, Profile T)
Almacenamiento en redNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
ProtocolosIPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP
Vista en vivo simultáneaUp to 20 channels
Usuario/operadorUp to 32 users. 3 user levels: administrator, operator, and user
SeguridadPassword protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark
ClienteiVMS-4200,HikCentral Pro,Hik-Connect
Navegador webIE 10+, Chrome 57+, Firefox 52+, Safari 12+

Imagen
Interruptor día/nocheDay,night,auto,schedule
Mejora de la imagenHLC,3D DNR
Wide Dynamic Range (WDR)[Bullet channel] No, [PTZ channel] 120 dB
DesempañarDigital defog
Image StabilizationEIS
Exposición regionalYes
Enfoque regional[Bullet channel] No, [PTZ channel] Yes
Configuración de imagenSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Interruptor de parámetros de imagenYes
Máscara de privacidad[Bullet channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
SNR≥ 52 dB

Supplement Detection
Posicionamiento satelitalNo
GyroscopeYes
BrújulaNo

Interfaz
Ethernet Interface1 RJ45 100M self-adaptive Ethernet port
Almacenamiento a bordoBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Alarma7 input(s), 2 output(s)
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
ReiniciarYes

Evento
Evento Básico[PTZ channel] video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception
Evento inteligente[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
Enlace de alarma[Bullet channel] no,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
Seguimiento inteligente[PTZ channel] yes
Smart Linkage3D positioning

Deep Learning Function
Multi-Target-Type Detection[Bullet channel] no,[PTZ channel] Supports simultaneous detection and capture of human body, face and vehicle

General
Función generalmirror,password protection
alimentación36 VDC ± 25%, max. 70 W,including max. 6 W for heater and max. 6 W for supplement light of bullet channel, and max. 6 W for heater and max. 15 W for supplement light of PTZ channel
Operating Condition-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)
Limpiador de lenteNo
DemistaYes
MaterialADC12
DimensiónØ290 mm × 453.2 mm (Ø11.42" × 17.84")
Approx. 11.5 kg (25.35 lb.)
Idioma33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Certificaciones
EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
SeguridadUL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
AmbienteCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
ProtecciónIP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection

Cámara

Sensor de imagen

[Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS

Iluminación mínima

[Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light, [PTZ channel] Color: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON), 0 lux with IR

Velocidad de obturación

1 s to 1/30000 s

Obturador lento

Yes

Día y Noche

[Bullet channel] Color, [PTZ channel] IR cut filter

Zoom

[PTZ channel] 25 × optical, 16 × digital

Max. Resolución

[Bullet channel] 3840 × 1080, [PTZ channel] 2560 × 1440

Lente

Enfoque

Auto,semi-auto,manual

Velocidad del Zoom

[Bullet channel] No, [PTZ channel] approx. 4.8 s

Longitud focal

[Bullet channel] 2.8 mm, [PTZ channel] 5.9 to 147.5 mm

FOV

[Bullet channel] horizontal field of view: 190° ± 5°, vertical field of view: 50° ± 5°, diagonal field of view: 198° ± 5°, [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 68.5° to 3.5°

Apertura

[Bullet channel] F1.0, [PTZ channel] F1.5

Iluminador

Rango de luz suplementaria

[Bullet channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m

Luz de suplemento inteligente

Yes

PTZ

Rango de movimiento (pan)

[PTZ channel] 0° to 360°

Rango de movimiento (tilt)

[Bullet channel] 7° to 17°, [PTZ channel] -20° to 90°

Velocidad de movimiento horizontal (pan)

[PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s

Velocidad de vertical (tilt)

[Bullet channel] tilt speed configurable,[PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s

Proportional Pan

[Bullet channel] No, [PTZ channel] Yes

Preajustes

300

Escaneo de patrulla

8 patrols, up to 32 presets for each patrol

Patrón de escaneo

4 pattern scans, record time over 10 minutes for each scan

Memoria de apagado

Yes

Acción del parque

Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan

Posicionamiento 3D

Yes

Pantalla de estado de PTZ

Yes

Congelación preestablecida

Yes

Tarea programada

Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output

Vídeo

Main stream

[Bullet channel] 50 Hz: 25 fps (3840 × 1080), 60 Hz: 24 fps (3840 × 1080),[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream

[Bullet channel] 50 Hz: 25 fps (1920 × 536), 60 Hz: 24 fps (1920 × 536),[PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

[Bullet channel] No,[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Compresión de vídeo

Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG

Vídeo bitrate

32 Kbps to 16 Mbps

Tipo H.264

Baseline profile,Main profile,High profile

Tipo H.265

Main profile

Codificación de video escalable (SVC)

H.264 and H.265 encoding

Región de interés (ROI)

8 fixed regions for each stream

Audio

Compresión de audio

G.711,G.722.1,G.726,MP2L2,PCM,AAC

Velocidad de bits de audio

32 to 192 Kbps (MP2L2),16 to 64 Kbps (AAC)

Frecuencia de muestreo de audio

8 kHz,16 kHz,32 kHz,48 kHz

Filtro de ruido ambiental

Yes

Red

API

ISUP,ISAPI,SDK,Open Network Video Interface (Profile S, Profile G, Profile T)

Almacenamiento en red

NAS (NFS, SMB/CIFS),auto network replenishment (ANR)

Protocolos

IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP

Vista en vivo simultánea

Up to 20 channels

Usuario/operador

Up to 32 users. 3 user levels: administrator, operator, and user

Seguridad

Password protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark

Cliente

iVMS-4200,HikCentral Pro,Hik-Connect

Navegador web

IE 10+, Chrome 57+, Firefox 52+, Safari 12+

Imagen

Interruptor día/noche

Day,night,auto,schedule

Mejora de la imagen

HLC,3D DNR

Wide Dynamic Range (WDR)

[Bullet channel] No, [PTZ channel] 120 dB

Desempañar

Digital defog

Image Stabilization

EIS

Exposición regional

Yes

Enfoque regional

[Bullet channel] No, [PTZ channel] Yes

Configuración de imagen

Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser

Interruptor de parámetros de imagen

Yes

Máscara de privacidad

[Bullet channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable

SNR

≥ 52 dB

Supplement Detection

Posicionamiento satelital

Gyroscope

Yes

Brújula

Interfaz

Ethernet Interface

1 RJ45 100M self-adaptive Ethernet port

Almacenamiento a bordo

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

Alarma

7 input(s), 2 output(s)

Audio

1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω

RS-485

1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

Reiniciar

Yes

Evento

Evento Básico

[PTZ channel] video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception

Evento inteligente

[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection

Enlace de alarma

[Bullet channel] no,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)

Seguimiento inteligente

[PTZ channel] yes

Smart Linkage

3D positioning

Deep Learning Function

Multi-Target-Type Detection

[Bullet channel] no,[PTZ channel] Supports simultaneous detection and capture of human body, face and vehicle

General

Función general

mirror,password protection

alimentación

36 VDC ± 25%, max. 70 W,including max. 6 W for heater and max. 6 W for supplement light of bullet channel, and max. 6 W for heater and max. 15 W for supplement light of PTZ channel

Operating Condition

-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)

Limpiador de lente

Demista

Yes

Material

ADC12

Dimensión

Ø290 mm × 453.2 mm (Ø11.42" × 17.84")

Approx. 11.5 kg (25.35 lb.)

Idioma

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Certificaciones

EMC

FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)

Seguridad

UL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)

Ambiente

CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)

Protección

IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection

Cámara

Sensor de imagen[Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS
Iluminación mínima[Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light, [PTZ channel] Color: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON), 0 lux with IR
Velocidad de obturación1 s to 1/30000 s
Obturador lentoYes
Día y Noche[Bullet channel] Color, [PTZ channel] IR cut filter
Zoom[PTZ channel] 25 × optical, 16 × digital
Max. Resolución[Bullet channel] 3840 × 1080, [PTZ channel] 2560 × 1440

Lente

EnfoqueAuto,semi-auto,manual
Velocidad del Zoom[Bullet channel] No, [PTZ channel] approx. 4.8 s
Longitud focal[Bullet channel] 2.8 mm, [PTZ channel] 5.9 to 147.5 mm
FOV[Bullet channel] horizontal field of view: 190° ± 5°, vertical field of view: 50° ± 5°, diagonal field of view: 198° ± 5°, [PTZ channel] horizontal field of view: 58.5° to 3.1°, vertical field of view: 34° to 1.7°, diagonal field of view: 68.5° to 3.5°
Apertura[Bullet channel] F1.0, [PTZ channel] F1.5

Iluminador

Rango de luz suplementaria[Bullet channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m
Luz de suplemento inteligenteYes

PTZ

Rango de movimiento (pan) [PTZ channel] 0° to 360°
Rango de movimiento (tilt)[Bullet channel] 7° to 17°, [PTZ channel] -20° to 90°
Velocidad de movimiento horizontal (pan)[PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s
Velocidad de vertical (tilt)[Bullet channel] tilt speed configurable,[PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
Proportional Pan[Bullet channel] No, [PTZ channel] Yes
Preajustes300
Escaneo de patrulla8 patrols, up to 32 presets for each patrol
Patrón de escaneo4 pattern scans, record time over 10 minutes for each scan
Memoria de apagadoYes
Acción del parquePreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan
Posicionamiento 3DYes
Pantalla de estado de PTZYes
Congelación preestablecidaYes
Tarea programadaPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output

Vídeo

Main stream[Bullet channel] 50 Hz: 25 fps (3840 × 1080), 60 Hz: 24 fps (3840 × 1080),[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream[Bullet channel] 50 Hz: 25 fps (1920 × 536), 60 Hz: 24 fps (1920 × 536),[PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream[Bullet channel] No,[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Compresión de vídeoMain stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Vídeo bitrate32 Kbps to 16 Mbps
Tipo H.264Baseline profile,Main profile,High profile
Tipo H.265Main profile
Codificación de video escalable (SVC)H.264 and H.265 encoding
Región de interés (ROI)8 fixed regions for each stream

Audio

Compresión de audioG.711,G.722.1,G.726,MP2L2,PCM,AAC
Velocidad de bits de audio32 to 192 Kbps (MP2L2),16 to 64 Kbps (AAC)
Frecuencia de muestreo de audio8 kHz,16 kHz,32 kHz,48 kHz
Filtro de ruido ambientalYes

Red

APIISUP,ISAPI,SDK,Open Network Video Interface (Profile S, Profile G, Profile T)
Almacenamiento en redNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
ProtocolosIPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP
Vista en vivo simultáneaUp to 20 channels
Usuario/operadorUp to 32 users. 3 user levels: administrator, operator, and user
SeguridadPassword protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark
ClienteiVMS-4200,HikCentral Pro,Hik-Connect
Navegador webIE 10+, Chrome 57+, Firefox 52+, Safari 12+

Imagen

Interruptor día/nocheDay,night,auto,schedule
Mejora de la imagenHLC,3D DNR
Wide Dynamic Range (WDR)[Bullet channel] No, [PTZ channel] 120 dB
DesempañarDigital defog
Image StabilizationEIS
Exposición regionalYes
Enfoque regional[Bullet channel] No, [PTZ channel] Yes
Configuración de imagenSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Interruptor de parámetros de imagenYes
Máscara de privacidad[Bullet channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
SNR≥ 52 dB

Supplement Detection

Posicionamiento satelitalNo
GyroscopeYes
BrújulaNo

Interfaz

Ethernet Interface1 RJ45 100M self-adaptive Ethernet port
Almacenamiento a bordoBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Alarma7 input(s), 2 output(s)
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
ReiniciarYes

Evento

Evento Básico[PTZ channel] video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception
Evento inteligente[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
Enlace de alarma[Bullet channel] no,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
Seguimiento inteligente[PTZ channel] yes
Smart Linkage3D positioning

Deep Learning Function

Multi-Target-Type Detection[Bullet channel] no,[PTZ channel] Supports simultaneous detection and capture of human body, face and vehicle

General

Función generalmirror,password protection
alimentación36 VDC ± 25%, max. 70 W,including max. 6 W for heater and max. 6 W for supplement light of bullet channel, and max. 6 W for heater and max. 15 W for supplement light of PTZ channel
Operating Condition-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)
Limpiador de lenteNo
DemistaYes
MaterialADC12
DimensiónØ290 mm × 453.2 mm (Ø11.42" × 17.84")
Approx. 11.5 kg (25.35 lb.)
Idioma33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Certificaciones

EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
SeguridadUL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
AmbienteCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
ProtecciónIP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection
