5ch Dashcam 4G/GPS

  • Up to 1440P resolution, with 127° FOV
  • Supports two-way audio
  • Supports GPS and speed overlay on picture
  • Built-in Wi-Fi module, supports Wi-Fi AP
  • Supports 4G network
  • Supports dual-TF card storage and recording overwrite
  • Supports preview, playback and editing parameters via APP
  • Supports connecting to HCP&HCC for uploading and playback
  • Adopts build-in Gyroscope
  • Compatible with 4-ch TVI Camera
  • Supports two alarm input
  • Supports face detection, driver behavior analysis, advanced driving dssistance etc.
  • Easy installation and operation
  • Low power consumption and high performance

Available models:



  • Camera
  • Max. ResolutionUp to 1440P
  • Lens
  • Focal Length & FOV153°( diagonal), 127°(horizontal)
  • Iris TypeF2.0
  • Video
  • Main StreamCH1:1080P/720P CH2~CH5:720P
  • Sub-StreamCH1:720P/480P CH2~CH5:480P
  • Video Compression H.264/H.265
  • Frame Rate25FPS
  • Audio
  • Audio Compression G711_U/G711_A/AAC
  • Wi-Fi
  • Wi-Fi ProtocolIEEE 802.11b/g/n
  • Frequency Range2.4GHz
  • Mobile Communication
  • Mobile Communication TypeBaseline: FDD-LTE: B1, B3, B5, B8 TDD-LTE: B38, B39, B40, B41 TD-SCDMA: B34, B39 UMTS: B1, B8 EV-DO: BC0 CDMA 1x: BC0 GSM/GPRS/EDGE: 900/1800 MHz Australia: FDD-LTE: B1, B3, B5, B7, B28 TDD-LTE: B40 UMTS: B1, B5 Europe: FDD-LTE: B1, B3, B5, B7, B8, B20 TDD-LTE: B40 UMTS: B1, B8 GSM/GPRS/EDGE: 900/1800 MHz
  • SIM Card Typeindustry Micro SIM
  • Image
  • Wide Dynamic Range (WDR)Yes
  • Backlight Compensation(BLC)Yes
  • Electronic Image Stabilization(EIS)Yes
  • Distortion CorrectionYes
  • Highlight Compensation(HLC)Yes
  • Satellite Positioning
  • Satellite Positioning DetectionGPS
  • Interface
  • On-Board Storagedual 2 TF card,up to 256GB for ecah
  • Built-in MicrophoneYes
  • Built-in SpeakerBuilt-in Speaker
  • Alarm Supports 2 wired alarm button
  • RS-2321 RS-232 inteface
  • USB1 USB 2.0 interface
  • Indicator4G/REC/WIFI
  • Deep Learning Function
  • Face ComparisonSupports Face Comparison on device
  • Special Behavior AnalysisFatigue Driving/Make telephone calls/Smoking Alarm/Distraction Alarm
  • General
  • Power≤10W
  • Camera Dimension124x82x38mm
  • Package Dimension223x153x63mm
  • Camera Weight300g
  • Power SupplyDC 9~16V


Applied to:
Applied to:
*For better user experience, we highly recommend you to update your device to the latest firmware asap.
