DS-UL2

2MP Live Web Camera

View Less

Available models:

DS-UL2

Camera
Image Sensor2 MP CMOS
Signal SystemPAL/NTSC
Frame RateMJPG： 1920 × 1080 @60fps/50fps/30fps/25fps 1280 × 960 @60fps/50fps/30fps/25fps 1280 × 720 @60fps/50fps/30fps/25fps 640 × 480 @60fps/50fps/30fps/25fps 640 × 360 @60fps/50fps/30fps/25fps YUV2： 1920 × 1080 @5fps 1280 × 960 @5fps 1280 × 720 @10fps 640 × 480 @30fps 640 × 360 @30fps
Resolution1920 (H) × 1080 (V)
Min. Illumination0.1 Lux @ (F1.2, AGC ON)
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Lens3.6 mm fixed focal lens
Field of Viewhorizontal FOV: 87°, vertical FOV: 55°, diagonal FOV: 95°
Lens MountM8
Day & Night24/7 Color Imaging
Angle Adjustmentpan: 0°; tilt: 0° to 90°; rotation: 0°
Digital ZoomYes
Cable Length2 m

Interface
Video OutputUSB 2.0
Audio InBuilt-in mic
Operating SystemRecommended systems Windows 7/8/10/11 Android 8.1 and above version Linux 4.14 and above version macOS 10.12 and above version Chrome OS

Accessory
Packing ListCamera × 1 USB Cable × 1 Quick Start Guide × 1 Bracket × 1 Tripod × 1

Camera

Image Sensor

2 MP CMOS
