4-ch 1080p Lite 1U H.265 eSSD DVR

  • Powered by eSSD technology
  • Deep learning based human and vehicle targets classification of Motion Detection 2.0
  • Scene-adaptive bitrate control video compression
  • Up to 1080p Lite@30 fps encoding capability
  • Audio via coaxial cable
  • Low power consumption
View Less
View more

Available models:



  • Motion Detection 2.0
  • Human/Vehicle AnalysisDeep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
  • Recording
  • Video CompressionH.265 Pro/H.265
  • Encoding Resolution1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
  • Frame RateMain stream: 1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N) Note: 1080p Lite/720p is 15 fps by default Sub-stream: 4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)
  • Video BitrateAccording to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.
  • Stream TypeVideo, Video & Audio Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
  • Audio CompressionG.711u
  • Audio Bitrate64 Kbps
  • Video and Audio
  • IP Video Input1-ch Up to 1080p resolution Support H.265+/H.265 IP cameras
  • Analog Video Input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • HDTVI Input1080p25, 1080p30, 720p25, 720p30
  • AHD Input1080p25, 1080p30, 720p25, 720p30
  • CVBS InputSupport
  • HDCVI Input1080p25, 1080p30, 720p25, 720p30
  • HDMI Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
  • VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
  • Video Output ModeHDMI/VGA simultaneous output
  • Audio Input4-ch via coaxial cable
  • Audio Output1-ch via HDMI
  • Synchronous playback4-ch
  • Network
  • Total Bandwidth64 Mbps Incoming bandwidth: 4 Mbps
  • Network ProtocolTCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
  • Remote Connection32
  • Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
  • Auxiliary Interface
  • CapacityBuilt-in 330 GB eSSD (300 GB available) Note: The device can store about 2 weeks videos for 4-ch analog cameras (default parameters), this estimation is for reference only.
  • USB InterfaceRear panel: 2 × USB 2.0
  • Alarm In/OutN/A
  • General
  • Power Supply12 VDC, 1 A
  • Consumption≤ 5.4 W (with eSSD)
  • Working Temperature-10 °C to 45 °C (14 °F to +113 °F)
