Thermographic Thermal & Optical Bi-spectrum Network Speed Dome

Perimeter protection function, based on deep learning algorithm: line crossing, intrusion, region entrance and exit
Temperature exception alarm for fire prevention
640× 512 (the resolution of output image is 1920 × 1080) resolution 17 μm, VOx UFPA, NETD ≤ 35 mK (25 °C, F# = 1.1)
Image processing technology: Liner, histogram, and self-adaptive thermal AGC mode, DDE, 3D DNR
High quality detector with 10 years guarantee
Smart tracking: Panorama tracking, Event tracking and Multi-scene patrol tracking
Thermal channel supports EIS, conflicted with intelligent function
Fire and smoke detection algorithm

View Less

Data Sheet

Available models:

DS-2TD4167T-25/W(B)

DS-2TD4167T-25/W

Spezifikation
Resources
Zubehör

Data Sheet

Thermalmodul
BildsensorVanadium Oxide Uncooled Focal Plane Arrays
Auflösung der Kamera640 × 512 (the resolution of output image is 1920 × 1080)
Pixel-Intervall17 μm
Antwort-Wellenband8 μm to 14 μm
NETD≤35 mK (@25°C,F#=1.1)
Brennweite25 mm
Fokus-ModusSemi-auto & Manual
IFOV0.68 mrad
BlendeF1.0
Blickwinkel24.5 ° × 19.7 ° (H × V)
Min. Fokussierentfernung1.5 m
Digitaler Zoom×2, ×4, ×8

Optisches Modul
Bildsensor1/1.8" Progressive Scan CMOS
Auflösung der Kamera2688 × 1520, 4 MP
Min. BeleuchtungColor: 0.005 Lux @ (F1.3，AGC ON), B/W: 0.001 Lux @ (F1.3，AGC ON)
Blickwinkel56.6 ° × 33.7 °(H × V) to 1.8 ° × 1.0 ° (H × V)
Brennweite6-240 mm, 40x
Aperture (Range)F1.3-F4.6
Fokus-ModusAuto/Semi-auto/Manual
Digitaler Zoom×2, ×4, ×8, ×16
Verschlusszeit1 s to 1/30,000 s
WDR120 dB
Optical DefogYes

Image Effect
Picture in PictureDisplay partial image of thermal channel on the full screen of optical channel
Target ColorationSupported in white hot and black hot mode

PTZ
BewegungsbereichPan: 360° Continuous Rotate; Tilt: From -20° to + 90° (auto flip)
Pan SpeedConfigurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s
Tilt SpeedConfigurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s
ProportionalzoomYes
Presets300 in total, 273 are configurable.
Wächterrundgang8; Up to 32 Presets Per Patrol
Muster-Rundgang4; More Than 10 Minutes Per Pattern
Power Off MemoryYes
ParkPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PT StatusTurn On/Turn Off
Geplante AufgabePreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Strahler
IR-ReichweiteUp to 200 m
IR-Intensität und WinkelAutomatically adjusted

Intelligente Funktion
VCASupport 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
Temperature MeasurementSupport 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)
Temperature Range- 20° C to 550° C (- 4° F to 1022° F)
TemperaturgenauigkeitMax (± 2° C, ± 2 %)
BranderkennungDynamic fire detection, up to 10 fire points detectable.

Video and Audio
HauptstromOptical channel 50 Hz:25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz:30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)
Sub-StreamOptical channel 50 Hz:25 fps (704 × 576, 352 × 288) 60 Hz:30 fps (704 × 576, 352 × 288) Thermal channel 50 fps (704 × 576, 640 × 512, 384 × 288)
Video-KomprimierungMain stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG
Audio-KomprimierungG.711u/G.711a/G.722.1/MP2L2/G.726/PCM

Netzwerk
ProtokolleIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Netzwerk-SpeicherungMicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
APIISAPI, HIKVISION SDK, third-party management platform, ONVIF profile S,T,G)
Gleichzeitige Live-AnsichtUp to 20 channels
Benutzer- / Host-LevelUp to 32 users, 3 levels: Administrator, Operator, User
SicherheitUser authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
ClientiVMS-4200, Hik-Connect
WebbrowserLive view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0 +, Firefox 52.0 +

Schnittstelle
Alarm-Eingang7-ch inputs (0-5 VDC)
Alarm-Ausgang2-ch relay outputs, alarm response actions configurable
AlarmaktionPreset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Audio-Eingang1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio-AusgangLinear Level; Impedance: 600 Ω
Kommunikationsschnittstelle1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface
Analoger Videoausgang1.0 V [p-p]/75 Ω

Allgemein
Sprache Web Client32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Spannungsversorgung24V AC ± 20%, 36V DC ± 20%, 48V DC ± 20%, Hi-PoE
Leistungsaufnahme65W Max
Working Temperature/HumidityFrom - 40° C to 65° C (- 40° F to 149° F) 95% or less
WischerYes
SchutzklasseIP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Abmessung266.6 mm × 410 mm × 198.6 mm (10.5" × 16.15" × 7.82")
Approx. 9 kg (19.84 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich
VCA-Bereich Menschen175 m
VCA-Bereich Fahrzeuge525 m

Genehmigung
EMVCE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
SicherheitCB: IEC 62368-1: 2014+A11; CE-LVD: EN 62368-1: 2014/A11: 2017; BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005
UmgebungCE-RoHS：2011/65/EU, WEEE: 2012/19/EU, Reach：Regulation(EC) No 1907/2006
SchutzIP66: IEC 60529-2013

Thermalmodul

Bildsensor

Vanadium Oxide Uncooled Focal Plane Arrays

Auflösung der Kamera

640 × 512 (the resolution of output image is 1920 × 1080)

Pixel-Intervall

17 μm

Antwort-Wellenband

8 μm to 14 μm

NETD

≤35 mK (@25°C,F#=1.1)

Brennweite

25 mm

Fokus-Modus

Semi-auto & Manual

IFOV

0.68 mrad

Blende

F1.0

Blickwinkel

24.5 ° × 19.7 ° (H × V)

Min. Fokussierentfernung

1.5 m

Digitaler Zoom

×2, ×4, ×8

Optisches Modul

Bildsensor

1/1.8" Progressive Scan CMOS

Auflösung der Kamera

2688 × 1520, 4 MP

Min. Beleuchtung

Color: 0.005 Lux @ (F1.3，AGC ON), B/W: 0.001 Lux @ (F1.3，AGC ON)

Blickwinkel

56.6 ° × 33.7 °(H × V) to 1.8 ° × 1.0 ° (H × V)

Brennweite

6-240 mm, 40x

Aperture (Range)

F1.3-F4.6

Fokus-Modus

Auto/Semi-auto/Manual

Digitaler Zoom

×2, ×4, ×8, ×16

Verschlusszeit

1 s to 1/30,000 s

WDR

120 dB

Optical Defog

Yes

Image Effect

Picture in Picture

Display partial image of thermal channel on the full screen of optical channel

Target Coloration

Supported in white hot and black hot mode

PTZ

Bewegungsbereich

Pan: 360° Continuous Rotate; Tilt: From -20° to + 90° (auto flip)

Pan Speed

Configurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s

Tilt Speed

Configurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s

Proportionalzoom

Yes

Presets

300 in total, 273 are configurable.

Wächterrundgang

8; Up to 32 Presets Per Patrol

Muster-Rundgang

4; More Than 10 Minutes Per Pattern

Power Off Memory

Yes

Park

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

PT Status

Turn On/Turn Off

Geplante Aufgabe

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Strahler

IR-Reichweite

Up to 200 m

IR-Intensität und Winkel

Automatically adjusted

Intelligente Funktion

VCA

Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene

Temperature Measurement

Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)

Temperature Range

- 20° C to 550° C (- 4° F to 1022° F)

Temperaturgenauigkeit

Max (± 2° C, ± 2 %)

Branderkennung

Dynamic fire detection, up to 10 fire points detectable.

Video and Audio

Hauptstrom

Optical channel 50 Hz:25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz:30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)

Sub-Stream

Optical channel 50 Hz:25 fps (704 × 576, 352 × 288) 60 Hz:30 fps (704 × 576, 352 × 288) Thermal channel 50 fps (704 × 576, 640 × 512, 384 × 288)

Video-Komprimierung

Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG

Audio-Komprimierung

G.711u/G.711a/G.722.1/MP2L2/G.726/PCM

Netzwerk

Protokolle

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Netzwerk-Speicherung

MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

API

ISAPI, HIKVISION SDK, third-party management platform, ONVIF profile S,T,G)

Gleichzeitige Live-Ansicht

Up to 20 channels

Benutzer- / Host-Level

Up to 32 users, 3 levels: Administrator, Operator, User

Sicherheit

User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering

Client

iVMS-4200, Hik-Connect

Webbrowser

Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0 +, Firefox 52.0 +

Schnittstelle

Alarm-Eingang

7-ch inputs (0-5 VDC)

Alarm-Ausgang

2-ch relay outputs, alarm response actions configurable

Alarmaktion

Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage

Audio-Eingang

1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%

Audio-Ausgang

Linear Level; Impedance: 600 Ω

Kommunikationsschnittstelle

1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface

Analoger Videoausgang

1.0 V [p-p]/75 Ω

Allgemein

Sprache Web Client

32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Spannungsversorgung

24V AC ± 20%, 36V DC ± 20%, 48V DC ± 20%, Hi-PoE

Leistungsaufnahme

65W Max

Working Temperature/Humidity

From - 40° C to 65° C (- 40° F to 149° F) 95% or less

Wischer

Yes

Schutzklasse

IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Abmessung

266.6 mm × 410 mm × 198.6 mm (10.5" × 16.15" × 7.82")

Approx. 9 kg (19.84 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich

VCA-Bereich Menschen

175 m

VCA-Bereich Fahrzeuge

525 m

Genehmigung

EMV

CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
