Thermal & Optical Bi-spectrum Network Stable PTZ Camera

Perimeter protection function, based on intelligent algorithm: line crossing, intrusion, region entrance and exit
Temperature exception alarm for fire prevention
Fire detection algorithm, Smoke detection algorithm
640 × 512 (the resolution of output image is 1920 × 1080) resolution 17 μm, VOx UFPA, NETD ≤ 35 mK (25 °C, F# = 1.0)
Image processing technology: Liner, histogram, and self-adaptive thermal AGC mode, DDE, 3D DNR
High quality detector with 10 years guarantee
Smart tracking: Panorama tracking, Event tracking and Multi-scene patrol tracking
Smart tracking linkage: thermal view and optical view
Thermal channel and optical channel supports EIS, conflicted with intelligent function
Support vessel detection like dredger, fishing boat and ship flow detection

View Less

Data Sheet

Verfügbare Modelle:

DS-2TD8167-150ZC4F/W

Spezifikation
Ressourcen
Zubehör

Data Sheet

Thermalmodul
BildsensorVanadium Oxide Uncooled Focal Plane Arrays
Auflösung der Kamera640 × 512 (the resolution of output image is 1920 × 1080)
Pixel Pitch17 μm
Spectral Range8 μm to 14 μm
NETDLess than 35 mK (@25 °C,F#=1.0)
Brennweite30 to 150 mm
Fokus-ModusSemi-auto & Manual
IFOV0.57 to 0.11 mrad
BlendeF0.8 to F1.2
Blickwinkel20.56° × 16.51° (H × V) to 4.15° × 3.32° (H × V)
Min. Fokussierentfernung3m
Digitaler Zoom×2, ×4, ×8

Optisches Modul
Bildsensor1/1.8" Progressive Scan CMOS
Auflösung der Kamera2688 × 1520, 4 MP
Min. BeleuchtungColor: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON)
Blickwinkel60° × 35.8° (H × V) to 1.2° × 0.7° (H × V)
Brennweite6.7 to 360mm, 54X
Aperture (Range)F1.36-F4.6
Fokus-ModusSemi-auto/Manual
Verschlusszeit1s to 1/30,000s
WDR120 dB
Digitaler Zoom×2, ×4, ×8, ×16
Optical DefogYes

Image Effect
Picture in PictureDisplay partial image of thermal channel on the full screen of optical channel
Target ColorationSupported in white hot and black hot mode

PTZ
BewegungsbereichPan: 360° Continuous Rotate; Tilt: From -45° to + 45° (auto flip)
Pan SpeedConfigurable, From 0.01°/s to 40°/s, Preset Speed: 240°/s
Tilt SpeedConfigurable, From 0.01°/s to 20°/s, Preset Speed: 200°/s
ProportionalzoomYes
Presets300 in total, 273 are configurable.
Wächterrundgang8; Up to 32 Presets Per Patrol
Muster-Rundgang4; More Than 10 Minutes Per Pattern
Power Off MemoryYes
ParkPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PT StatusTurn On/Turn Off
Geplante AufgabePreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Intelligente Funktion
VCASupport 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
Temperature MeasurementSupport 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)
Temperature Range-20 °C to 150 °C (-4 °F to 302 °F)
Temperaturgenauigkeit± 8 °C (±14.4 °F)
BranderkennungDynamic fire point detection, up to 10 fire points detectable.

Video and Audio
HauptstromOptical channel 50 Hz:25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 384 × 288)
Sub-StreamOptical channel 50 Hz:25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 576, 352 × 288) Thermal channel 50 fps (704 × 576, 640 × 480, 384 × 288)
Video-KomprimierungMain stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG
Audio-KomprimierungG .711u/G.711a/G.722.1/MP2L2/G.726/PCM

Video and Image
Color Palettes17 types (White hot, Black hot, Fusion 1, Rainbow, Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice fire, Rain, Red hot, Green hot, Dark blue, Winter, Summer)

Netzwerk
ProtokolleIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Netzwerk-SpeicherungMicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
APIISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T)
Gleichzeitige Live-AnsichtUp to 20 channels
Benutzer- / Host-LevelUp to 32 users, 3 levels: Administrator, Operator, User
SicherheitUser authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
ClientiVMS-4200, Hik-Connect
WebbrowserLive view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Schnittstelle
Alarm-Eingang7-ch inputs (0-5 VDC)
Alarm-Ausgang2-ch relay outputs, alarm response actions configurable
AlarmaktionPreset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Audio-Eingang1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio-AusgangLinear Level; Impedance: 600 Ω
Kommunikationsschnittstelle1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface
Analog Output1.0 V [p-p]/75 Ω, BNC for thermal channel

Allgemein
Menu Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Spannungsversorgung48 VDC ± 20%, two-core terminal block
LeistungsaufnahmeBasic: ＜190W; Max: ＜270W (Heater on)
Working Temperature/HumidityFrom -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less
WischerYes
SchutzklasseIP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Abmessungen559 mm × 379 mm × 646 mm (22.0 " × 14.9 " × 25.4 ")
Approx. 60kg (132.3 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich
VCA-Bereich Menschen1050 m
VCA-Bereich Fahrzeuge3150 m

Genehmigung
EMVCE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
SicherheitCB: IEC 62368-1: 2014+A11; CE-LVD: EN 62368-1: 2014/A11: 2017; BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005 FCC: CFR 47 FCC Part 15 subpart B
UmgebungCE-RoHS：2011/65/EU, Reach：Regulation(EC) No 1907/2006
SchutzIP66: IEC 60529-2013

Thermalmodul

Bildsensor

Vanadium Oxide Uncooled Focal Plane Arrays

Auflösung der Kamera

640 × 512 (the resolution of output image is 1920 × 1080)

Pixel Pitch

17 μm

Spectral Range

8 μm to 14 μm

NETD

Less than 35 mK (@25 °C,F#=1.0)

Brennweite

30 to 150 mm

Fokus-Modus

Semi-auto & Manual

IFOV

0.57 to 0.11 mrad

Blende

F0.8 to F1.2

Blickwinkel

20.56° × 16.51° (H × V) to 4.15° × 3.32° (H × V)

Min. Fokussierentfernung

Digitaler Zoom

×2, ×4, ×8

Optisches Modul

Bildsensor

1/1.8" Progressive Scan CMOS

Auflösung der Kamera

2688 × 1520, 4 MP

Min. Beleuchtung

Color: 0.0005 Lux @ (F1.5, AGC ON), B/W: 0.0001 Lux @ (F1.5, AGC ON)

Blickwinkel

60° × 35.8° (H × V) to 1.2° × 0.7° (H × V)

Brennweite

6.7 to 360mm, 54X

Aperture (Range)

F1.36-F4.6

Fokus-Modus

Semi-auto/Manual

Verschlusszeit

1s to 1/30,000s

WDR

120 dB

Digitaler Zoom

×2, ×4, ×8, ×16

Optical Defog

Yes

Image Effect

Picture in Picture

Display partial image of thermal channel on the full screen of optical channel

Target Coloration

Supported in white hot and black hot mode

PTZ

Bewegungsbereich

Pan: 360° Continuous Rotate; Tilt: From -45° to + 45° (auto flip)

Pan Speed

Configurable, From 0.01°/s to 40°/s, Preset Speed: 240°/s

Tilt Speed

Configurable, From 0.01°/s to 20°/s, Preset Speed: 200°/s

Proportionalzoom

Yes

Presets

300 in total, 273 are configurable.

Wächterrundgang

8; Up to 32 Presets Per Patrol

Muster-Rundgang

4; More Than 10 Minutes Per Pattern

Power Off Memory

Yes

Park

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

PT Status

Turn On/Turn Off

Geplante Aufgabe

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Intelligente Funktion

VCA

Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene

Temperature Measurement

Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)

Temperature Range

-20 °C to 150 °C (-4 °F to 302 °F)

Temperaturgenauigkeit

± 8 °C (±14.4 °F)

Branderkennung

Dynamic fire point detection, up to 10 fire points detectable.

Video and Audio

Hauptstrom

Optical channel 50 Hz:25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720) Thermal channel 50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 384 × 288)

Sub-Stream

Optical channel 50 Hz:25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 576, 352 × 288) Thermal channel 50 fps (704 × 576, 640 × 480, 384 × 288)

Video-Komprimierung

Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG

Audio-Komprimierung

G .711u/G.711a/G.722.1/MP2L2/G.726/PCM

Video and Image

Color Palettes

17 types (White hot, Black hot, Fusion 1, Rainbow, Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice fire, Rain, Red hot, Green hot, Dark blue, Winter, Summer)

Netzwerk

Protokolle

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Netzwerk-Speicherung

MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

API

ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T)

Gleichzeitige Live-Ansicht

Up to 20 channels

Benutzer- / Host-Level

Up to 32 users, 3 levels: Administrator, Operator, User

Sicherheit

User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering

Client

iVMS-4200, Hik-Connect

Webbrowser

Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Schnittstelle

Alarm-Eingang

7-ch inputs (0-5 VDC)

Alarm-Ausgang

2-ch relay outputs, alarm response actions configurable

Alarmaktion

Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage

Audio-Eingang

1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%

Audio-Ausgang

Linear Level; Impedance: 600 Ω

Kommunikationsschnittstelle

1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface

Analog Output

1.0 V [p-p]/75 Ω, BNC for thermal channel

Allgemein

Menu Language

32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Spannungsversorgung

48 VDC ± 20%, two-core terminal block

Leistungsaufnahme

Basic: ＜190W; Max: ＜270W (Heater on)

Working Temperature/Humidity

From -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less

Wischer

Yes

Schutzklasse

IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Abmessungen

559 mm × 379 mm × 646 mm (22.0 " × 14.9 " × 25.4 ")

Approx. 60kg (132.3 lb)

Erkennungsbereichstabelle / Smart-Funktionsbereich

VCA-Bereich Menschen

1050 m

VCA-Bereich Fahrzeuge

3150 m

Genehmigung

EMV

CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7)
