5 MP IR ANPR Checkpoint Capture Unit

High quality imaging with 5 MP resolution(2/3'' GMOS)
Excellent low-light performance, Color: 0.001 Lux@(F1.4, AGC ON), B/W: 0.0005 Lux @ (F1.4, AGC ON)
Efficient H.265 compression technology
3D DNR technology delivers clean and sharp images
Support license plate recognition (LPR)
Vehicle feature recognition: vehicle type / color / manufacturer / license plate color recognition, no-plate vehicle capture
Violation behaviors detection: driving on lane line, lane change, wrong-way driving detection, seatbelt and phone call detection.
Application Scenarios: highway, tunnel, toll station, urban road, etc.

View Less

Data Sheet

Available models:

iDS-TCV500-BI(F)/1550/H1(24V)(EU-STD)

iDS-TCV500-BI(F)/1550/H1

iDS-TCV500-BI(F)/1140/H1/24V/AF(EU-STD)

iDS-TCV500-BI

Spezifikation
Resources
Zubehör

Data Sheet

Kamera
Bildsensor5 MP (2/3'' GMOS)
Max. Auflösung2464 × 2056
Min. BeleuchtungColor: 0.001 Lux @ (F1.4, AGC ON), B/W: 0.0005 Lux @ (F1.4, AGC ON), 0 Lux with IR
Verschlusszeit50 s to 20000 s
Tag & NachtIR cut filter

Objektiv
Objektivtyp Varifocal lens, manual adjustment, 15 to 50 mm
Focal Length & FOV15 to 50 mm, horizontal FOV 42.7° to 13.7°, vertical FOV 23.4° to 7.6°, diagonal FOV 49.7° to 15.8°
Focus Manual
BlendeF1.4-C

Strahler
Built-in Supplement Light TypeIR light
Light Bead3
Built-in Supplement Light RangeUp to 30 m
IR Wavelength850 nm
External Supplement LightStrobe and flash light

Video
Hauptstrom 50 Hz: 50 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)
Sub-Stream 50 Hz: 50 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)
3. Stream 50 Hz: 50 fps (2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2048 × 1536, 1920 × 1080, 704 × 576)
Videokompression Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Audiokomprimierung32 Kbps to 16 Mbps
H.264 TypBaseline profile/Main profile/High profile
H.265 TypMain Profile

Netzwerk
ProtokolleTCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,ISUP,ARP,IGMP
Gleichzeitige Live-AnsichtUp to 6 channels
APIONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M),ISAPI,SDK,ISUP
Benutzer / HostUp to 32 users 3 user levels: administrator, operator and user
SicherheitPassword protection,Complicated password,HTTPS encryption,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface
Netzwerk-SpeicherungMicro SD/TF card (512 GB),Local storage,CVR,NVR,ANR
ClientiVMS-4200 (Only for live view and LPR information search),Hik-Central Master,Hik-Central Pro,HikCentral Master Lite
WebbrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge

Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.
Tag & Nacht-UmschaltungAuto,Schedule,Manual
SNR60 dB
BildverbesserungBLC, HLC, 3D DNR

Schnittstelle
Ethernet Interface2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port(s)
On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card card, up to 512 GB
Alarm 2 input interfaces (T1, SYNC), 7 output interfaces
RS-4853 RS-485 interfaces (half duplex, HIKVISION)
RS-2321 RS-232 interface
USB1 USB 2.0 interface

Ereignis
Normales EreignisHDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception

Straßenverkehr und Fahrzeugerkennung
CoverageUp to 2 lane(s)
Trigger ModeExternal I/O trigger/Radar trigger/Video trigger
Intelligente FunktionLicense plate recognition,Vehicle type classification,Vehicle color recognition,No-plate vehicle capture,Moving direction detection
LPR Countries/RegionsMiddle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain, Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria, Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka, America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala, Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina, Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
Accuracy (Under recommended installation and lighting conditions)Capture rate > 99%, Vehicle moving direction recognition accuracy > 98.5%, LPR accuracy > 98%, Mistaken capture rate < 2%
Keine KennzeichenerkennungSupported
Motorrad KennzeichenerkennungSupported
Vehicle TypeCar,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
Vehicle ColorRed, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only.
Vehicle Manufacturer84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO, Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng, Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton, HICOM, Malaysia_Unknown 1, Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, Beiben Truck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO
License Plate Color RecognitionCustomized to support
Driving on Lane Line DetectionSupported (only strobe light mode)
Lane Change DetectionSupported (only strobe light mode)
Wrong-Way Driving DetectionSupported
Emergency Lane OccupationSupported (with flash supplement light)
Seatbelt DetectionSupported (with flash supplement light)
Phone Call DetectionSupported (with flash supplement light)
Capture Speed Range10 to 320 km/h

Allgemein
Operating SystemLinux
PowerAC 100 V to 240 V, 1.5 A, max. 35 W, 3-core terminal block
MaterialAluminum alloy
Abmessung501.0 mm × 175.6 mm × 144.6 mm (19.72" × 6.92" × 5.69") (L × W × H)
Paketgröße667 mm × 357 mm × 224 mm (26.26" × 14.06" × 8.82") (L × W × H)
Weight Approx. 5.13 kg (11.31 lb.)
Mit PaketgewichtApprox. 7.4 kg (16.31 lb.)
Operating Condition-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)
Storage Condition-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (Non-condensing)
Allgemeine FunktionPassword protection,Three streams,Heartbeat,One-key reset,Pixel counter
Sprache8 languages: English, Russian, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
HeizungSupported

Genehmigung
EMVCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
SicherheitCE-LVD: EN 62368-1: 2014/A11: 2017,CB: IEC 62368-1: 2014+A11,CB: IEC 62368-1: 2018+A11
UmgebungCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
SchutzIK10: IEC 62262:2002,IP67: IEC 60529-2013

Kamera

Bildsensor

5 MP (2/3'' GMOS)

Max. Auflösung

2464 × 2056

Min. Beleuchtung

Color: 0.001 Lux @ (F1.4, AGC ON), B/W: 0.0005 Lux @ (F1.4, AGC ON), 0 Lux with IR

Verschlusszeit

50 s to 20000 s

Tag & Nacht

IR cut filter

Objektiv

Objektivtyp

Varifocal lens, manual adjustment, 15 to 50 mm

Focal Length & FOV

15 to 50 mm, horizontal FOV 42.7° to 13.7°, vertical FOV 23.4° to 7.6°, diagonal FOV 49.7° to 15.8°

Focus

Manual

Blende

F1.4-C

Strahler

Built-in Supplement Light Type

IR light

Light Bead

Built-in Supplement Light Range

Up to 30 m

IR Wavelength

850 nm

External Supplement Light

Strobe and flash light

Video

Hauptstrom

50 Hz: 50 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)

Sub-Stream

50 Hz: 50 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)

3. Stream

50 Hz: 50 fps (2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2048 × 1536, 1920 × 1080, 704 × 576)

Videokompression

Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG

Audiokomprimierung

32 Kbps to 16 Mbps

H.264 Typ

Baseline profile/Main profile/High profile

H.265 Typ

Main Profile

Netzwerk

Protokolle

TCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,ISUP,ARP,IGMP

Gleichzeitige Live-Ansicht

Up to 6 channels

API

ONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M),ISAPI,SDK,ISUP

Benutzer / Host

Up to 32 users 3 user levels: administrator, operator and user

Sicherheit

Password protection,Complicated password,HTTPS encryption,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface

Netzwerk-Speicherung

Micro SD/TF card (512 GB),Local storage,CVR,NVR,ANR

Client

iVMS-4200 (Only for live view and LPR information search),Hik-Central Master,Hik-Central Pro,HikCentral Master Lite

Webbrowser

Chrome V61+, IE9 to IE11, Firefox V41+, Edge


Image Settings

Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.

Tag & Nacht-Umschaltung

Auto,Schedule,Manual

SNR

60 dB

Bildverbesserung

BLC, HLC, 3D DNR

Schnittstelle

Ethernet Interface

2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port(s)

On-Board Storage

Built-in memory card slot, supporting microSD/SDHC/SDXC card card, up to 512 GB

Alarm

2 input interfaces (T1, SYNC), 7 output interfaces

RS-485

3 RS-485 interfaces (half duplex, HIKVISION)

RS-232

1 RS-232 interface

USB

1 USB 2.0 interface

Ereignis

Normales Ereignis

HDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception

Straßenverkehr und Fahrzeugerkennung

Coverage

Up to 2 lane(s)

Trigger Mode

External I/O trigger/Radar trigger/Video trigger

Intelligente Funktion

License plate recognition,Vehicle type classification,Vehicle color recognition,No-plate vehicle capture,Moving direction detection

LPR Countries/Regions

Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain, Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria, Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka, America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala, Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina, Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan

Accuracy (Under recommended installation and lighting conditions)

Capture rate > 99%, Vehicle moving direction recognition accuracy > 98.5%, LPR accuracy > 98%, Mistaken capture rate < 2%

Keine Kennzeichenerkennung

Supported

Motorrad Kennzeichenerkennung

Supported

Vehicle Type

Car,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle

Vehicle Color

Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only.

Vehicle Manufacturer

84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO, Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng, Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton, HICOM, Malaysia_Unknown 1, Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, Beiben Truck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO

License Plate Color Recognition

Customized to support

Driving on Lane Line Detection

Supported (only strobe light mode)

Lane Change Detection

Supported (only strobe light mode)

Wrong-Way Driving Detection

Supported

Emergency Lane Occupation

Supported (with flash supplement light)

Seatbelt Detection

Supported (with flash supplement light)

Phone Call Detection

Supported (with flash supplement light)

Capture Speed Range

10 to 320 km/h

Allgemein

Operating System

Linux

Power

AC 100 V to 240 V, 1.5 A, max. 35 W, 3-core terminal block

Material

Aluminum alloy

Abmessung

501.0 mm × 175.6 mm × 144.6 mm (19.72" × 6.92" × 5.69") (L × W × H)

Paketgröße

667 mm × 357 mm × 224 mm (26.26" × 14.06" × 8.82") (L × W × H)

Weight

Approx. 5.13 kg (11.31 lb.)

Mit Paketgewicht

Approx. 7.4 kg (16.31 lb.)

Operating Condition

-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)

Storage Condition

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (Non-condensing)

Allgemeine Funktion

Password protection,Three streams,Heartbeat,One-key reset,Pixel counter

Sprache

8 languages: English, Russian, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish

Heizung

Supported

Genehmigung

EMV

CE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014

Sicherheit

CE-LVD: EN 62368-1: 2014/A11: 2017,CB: IEC 62368-1: 2014+A11,CB: IEC 62368-1: 2018+A11

Umgebung

CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006

Schutz

IK10: IEC 62262:2002,IP67: IEC 60529-2013

Kamera

Bildsensor5 MP (2/3'' GMOS)
Max. Auflösung2464 × 2056
Min. BeleuchtungColor: 0.001 Lux @ (F1.4, AGC ON), B/W: 0.0005 Lux @ (F1.4, AGC ON), 0 Lux with IR
Verschlusszeit50 s to 20000 s
Tag & NachtIR cut filter

Objektiv

Objektivtyp Varifocal lens, manual adjustment, 15 to 50 mm
Focal Length & FOV15 to 50 mm, horizontal FOV 42.7° to 13.7°, vertical FOV 23.4° to 7.6°, diagonal FOV 49.7° to 15.8°
Focus Manual
BlendeF1.4-C

Strahler

Built-in Supplement Light TypeIR light
Light Bead3
Built-in Supplement Light RangeUp to 30 m
IR Wavelength850 nm
External Supplement LightStrobe and flash light

Video

Hauptstrom 50 Hz: 50 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2464 × 2056, 2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)
Sub-Stream 50 Hz: 50 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2448 × 2048, 2048 × 1536, 1920 × 1080, 704 × 576)
3. Stream 50 Hz: 50 fps (2048 × 1536, 1920 × 1080, 704 × 576) 60 Hz: 30 fps (2048 × 1536, 1920 × 1080, 704 × 576)
Videokompression Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Audiokomprimierung32 Kbps to 16 Mbps
H.264 TypBaseline profile/Main profile/High profile
H.265 TypMain Profile

Netzwerk

ProtokolleTCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,ISUP,ARP,IGMP
Gleichzeitige Live-AnsichtUp to 6 channels
APIONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M),ISAPI,SDK,ISUP
Benutzer / HostUp to 32 users 3 user levels: administrator, operator and user
SicherheitPassword protection,Complicated password,HTTPS encryption,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface
Netzwerk-SpeicherungMicro SD/TF card (512 GB),Local storage,CVR,NVR,ANR
ClientiVMS-4200 (Only for live view and LPR information search),Hik-Central Master,Hik-Central Pro,HikCentral Master Lite
WebbrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge


Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.
Tag & Nacht-UmschaltungAuto,Schedule,Manual
SNR60 dB
BildverbesserungBLC, HLC, 3D DNR

Schnittstelle

Ethernet Interface2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port(s)
On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card card, up to 512 GB
Alarm 2 input interfaces (T1, SYNC), 7 output interfaces
RS-4853 RS-485 interfaces (half duplex, HIKVISION)
RS-2321 RS-232 interface
USB1 USB 2.0 interface

Ereignis

Normales EreignisHDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception

Straßenverkehr und Fahrzeugerkennung

CoverageUp to 2 lane(s)
Trigger ModeExternal I/O trigger/Radar trigger/Video trigger
Intelligente FunktionLicense plate recognition,Vehicle type classification,Vehicle color recognition,No-plate vehicle capture,Moving direction detection
LPR Countries/RegionsMiddle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain, Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria, Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka, America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala, Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina, Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
Accuracy (Under recommended installation and lighting conditions)Capture rate > 99%, Vehicle moving direction recognition accuracy > 98.5%, LPR accuracy > 98%, Mistaken capture rate < 2%
Keine KennzeichenerkennungSupported
Motorrad KennzeichenerkennungSupported
Vehicle TypeCar,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
Vehicle ColorRed, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only.
Vehicle Manufacturer84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO, Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng, Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton, HICOM, Malaysia_Unknown 1, Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, Beiben Truck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO
License Plate Color RecognitionCustomized to support
Driving on Lane Line DetectionSupported (only strobe light mode)
Lane Change DetectionSupported (only strobe light mode)
Wrong-Way Driving DetectionSupported
Emergency Lane OccupationSupported (with flash supplement light)
Seatbelt DetectionSupported (with flash supplement light)
Phone Call DetectionSupported (with flash supplement light)
Capture Speed Range10 to 320 km/h

Allgemein

Operating SystemLinux
PowerAC 100 V to 240 V, 1.5 A, max. 35 W, 3-core terminal block
MaterialAluminum alloy
Abmessung501.0 mm × 175.6 mm × 144.6 mm (19.72" × 6.92" × 5.69") (L × W × H)
Paketgröße667 mm × 357 mm × 224 mm (26.26" × 14.06" × 8.82") (L × W × H)
Weight Approx. 5.13 kg (11.31 lb.)
Mit PaketgewichtApprox. 7.4 kg (16.31 lb.)
Operating Condition-30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing)
Storage Condition-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (Non-condensing)
Allgemeine FunktionPassword protection,Three streams,Heartbeat,One-key reset,Pixel counter
Sprache8 languages: English, Russian, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
HeizungSupported

Genehmigung

EMVCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
SicherheitCE-LVD: EN 62368-1: 2014/A11: 2017,CB: IEC 62368-1: 2014+A11,CB: IEC 62368-1: 2018+A11
UmgebungCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
SchutzIK10: IEC 62262:2002,IP67: IEC 60529-2013
