DS-2CD3747G2T-LZSU

4 MP ColorVu Motorized Varifocal Dome Network Camera

24/7 Colorful imaging
Anti-Illuminator-Reflection
High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong back light due to 130 dB true WDR technology
Focus on human and vehicle target classification based on deep learning
Audio and alarm interfaces available
Water and dust resistant (IP67) and vandal resistant (IK10)

View Less

Available models:

DS-2CD3747G2T-LZSU(2.8-12mm)(C)

Kamera
Bildsensor1/1.8" Progressive Scan CMOS
Max. Auflösung2688 × 1520
Min. BeleuchtungColor: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Verschlusszeit1/3 s to 1/100,000 s
AusrichtungseinstellungPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Tag & Nacht24/7 color imaging

Objektiv
ObjektivtypVarifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV2.8 to 12 mm, horizontal FOV 105.4° to 56.4°, vertical FOV 53.9° to 31.6°, diagonal FOV 131.8° to 65.1°
ObjektivfassungIntegrated
Iris TypeDC iris
BlendeF1.0
Depth of Field1.9 m to ∞

DORI
DORID: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m

Strahler
ZusatzbeleuchtungWhite Light
Reichweite ZusatzbeleuchtungUp to 40 m
Intelligente ZusatzbeleuchtungYes

Video
Hauptstrom50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
3. Stream50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Videokompression Main stream: H.265/H.264/H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
Audiokomprimierung32 Kbps to 8 Mbps
4. Stream50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
H.264 TypBaseline Profile,Main Profile,High Profile
H.265 TypMain Profile
BitratensteuerungCBR,VBR
Skalierbare Videocodierung (SVC)H.264 and H.265 encoding
Region of Interest (ROI)1 fixed region(s) for main stream and sub-stream

Audio
Audiokomprimierung G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bitrate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio-Abtastrate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
UmgebungsgeräuschfilterungYes

Netzwerk
ProtokolleTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Gleichzeitige Live-AnsichtUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Benutzer / HostUp to 32 users 3 user levels: administrator, operator, and user
SicherheitPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Netzwerk-SpeicherungNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200,Hik-Connect,Hik-Central
WebbrowserPlug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Bildparameter wechselnYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Tag & Nacht-UmschaltungDay,Night,Auto,Schedule
Wide Dynamic Range (WDR)130 dB
SNR≥ 52 dB
BildverbesserungBLC,HLC,3D DNR
Privatzone4 programmable polygon privacy masks

Schnittstelle
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Audio1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Eingebautes MikrophonYes
Reset KeyYes
Leistungsabgabe12 VDC, max. 100 mA

Ereignis
Normales Ereignis Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error
Intelligentes Ereignis Unattended baggage detection,object removal detection,scene change detection,audio exception detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,trigger alarm output,audible warning,white light flashing

Deep Learning Function
GesichtserfassungYes
Perimeter Protection Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

Allgemein
Power 12 VDC ± 25%, 0.9 A, max. 10.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
MaterialMetal
AbmessungØ155 mm × 152 mm (Ø6.1" × 6.0")
Paketgröße227 mm × 198 mm × 220 mm (8.9" × 7.8" × 8.7")
Approx. 1600 g (3.4 lb.)
Mit PaketgewichtApprox. 2150 g (4.7 lb.)
Lagerbedingungen-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Anlauf- und Betriebsbedingungen-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Sprache33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Allgemeine FunktionHeartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter

Genehmigung
EMVFCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
SicherheitUL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, LOA: IEC/EN 60950-1
UmgebungCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
SchutzIP67: IEC 60529-2013,IK10: IEC 62262:2002

Spezifikation

Kamera

Bildsensor

1/1.8" Progressive Scan CMOS

Max. Auflösung

2688 × 1520

Min. Beleuchtung

Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light

Verschlusszeit

1/3 s to 1/100,000 s

Ausrichtungseinstellung

Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°

Tag & Nacht

24/7 color imaging

Objektiv

Objektivtyp

Varifocal lens, motorized lens, 2.8 to 12 mm

Focal Length & FOV

2.8 to 12 mm, horizontal FOV 105.4° to 56.4°, vertical FOV 53.9° to 31.6°, diagonal FOV 131.8° to 65.1°

Objektivfassung

Integrated

Iris Type

DC iris

Blende

F1.0

Depth of Field

1.9 m to ∞

DORI

D: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m

Strahler

Zusatzbeleuchtung

White Light

Reichweite Zusatzbeleuchtung

Up to 40 m

Intelligente Zusatzbeleuchtung

Yes

Video

Hauptstrom

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

3. Stream

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.

Videokompression

Main stream: H.265/H.264/H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.

Audiokomprimierung

32 Kbps to 8 Mbps

4. Stream

50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)

H.264 Typ

Baseline Profile,Main Profile,High Profile

H.265 Typ

Main Profile

Bitratensteuerung

CBR,VBR

Skalierbare Videocodierung (SVC)

H.264 and H.265 encoding

Region of Interest (ROI)

1 fixed region(s) for main stream and sub-stream

Audio

Audiokomprimierung

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Audio Bitrate

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

Audio-Abtastrate

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Umgebungsgeräuschfilterung

Yes

Netzwerk

Protokolle

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets

Gleichzeitige Live-Ansicht

Up to 6 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Benutzer / Host

Up to 32 users 3 user levels: administrator, operator, and user

Sicherheit

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

Netzwerk-Speicherung

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Client

iVMS-4200,Hik-Connect,Hik-Central

Webbrowser

Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+


Bildparameter wechseln

Yes

Image Settings

Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Tag & Nacht-Umschaltung

Day,Night,Auto,Schedule

Wide Dynamic Range (WDR)

130 dB

SNR

≥ 52 dB

Bildverbesserung

BLC,HLC,3D DNR

Privatzone

4 programmable polygon privacy masks

Schnittstelle

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Audio

1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarm

1 input, 1 output (max. 24 VDC/24 VAC, 1 A)

Eingebautes Mikrophon

Yes

Reset Key

Yes

Leistungsabgabe

12 VDC, max. 100 mA

Ereignis

Normales Ereignis

Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error

Intelligentes Ereignis

Unattended baggage detection,object removal detection,scene change detection,audio exception detection

Linkage

Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,trigger alarm output,audible warning,white light flashing

Deep Learning Function

Gesichtserfassung

Yes

Perimeter Protection

Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

Allgemein

Power

12 VDC ± 25%, 0.9 A, max. 10.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W

Material

Metal

Abmessung

Ø155 mm × 152 mm (Ø6.1" × 6.0")

Paketgröße

227 mm × 198 mm × 220 mm (8.9" × 7.8" × 8.7")

Approx. 1600 g (3.4 lb.)

Mit Paketgewicht

Approx. 2150 g (4.7 lb.)

Lagerbedingungen

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Anlauf- und Betriebsbedingungen

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Sprache

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Allgemeine Funktion

Heartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter

Genehmigung

EMV

FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015

Sicherheit

UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, LOA: IEC/EN 60950-1

Umgebung

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Schutz

IP67: IEC 60529-2013,IK10: IEC 62262:2002
