4 MP ColorVu Motorized Varifocal Bullet Network Camera

  • High quality imaging with 4 MP resolution
  • Motorized varifocal lens for easy installation and monitoring
  • 24/7 colorful imaging
  • Clear imaging against strong backlight due to 130 dB WDR technology
  • Focus on human and vehicle targets classification based on deep learning
  • Efficient H.265+ compression technology
  • Water and dust resistant (IP67) and vandal resistant (IK10)

View Less
View more

Available models:

DS-2CD2647G2T-LZS(2.8-12mm)(C)
Spezifikation
  • Kamera
  • Bildsensor 1/1.8" Progressive Scan CMOS
  • Max. Auflösung 2688 × 1520
  • Min. Beleuchtung Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
  • Verschlusszeit 1/3 s to 1/100,000 s
  • Ausrichtungseinstellung Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°
  • Tag & Nacht 24/7 color imaging
  • Objektiv
  • Objektivtyp Varifocal lens, motorized lens, 2.8 to 12 mm
  • Focal Length & FOV 2.8 to 12 mm, horizontal FOV 105.4° to 56.4°, vertical FOV 53.9° to 31.6°, diagonal FOV 131.8° to 65.1°
  • Objektivfassung Integrated
  • Fokus Auto,Semi-auto,Manual
  • Iris Type DC iris
  • Blende F1.0
  • Depth of Field 1.9 m to ∞
  • DORI
  • DORI D: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m
  • Strahler
  • Zusatzbeleuchtung White Light
  • Reichweite Zusatzbeleuchtung Up to 60 m
  • Intelligente Zusatzbeleuchtung Yes
  • Video
  • Hauptstrom 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
  • 3. Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
  • Videokompression Main stream: H.265/H.264/H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
  • Audiokomprimierung 32 Kbps to 8 Mbps
  • H.264 Typ Baseline Profile,Main Profile,High Profile
  • H.265 Typ Main Profile
  • Bitratensteuerung CBR,VBR
  • Skalierbare Videocodierung (SVC) H.264 and H.265 encoding
  • Region of Interest (ROI) 1 fixed region(s) for main stream and sub-stream
  • Audio
  • Audiokomprimierung G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bitrate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio-Abtastrate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Umgebungsgeräuschfilterung Yes
  • Netzwerk
  • Protokolle TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
  • Gleichzeitige Live-Ansicht Up to 6 channels
  • API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
  • Benutzer / Host Up to 32 users 3 user levels: administrator, operator, and user
  • Sicherheit Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
  • Netzwerk-Speicherung NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • Client iVMS-4200,Hik-Connect,Hik-Central
  • Webbrowser Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
  • Bild
  • Bildparameter wechseln Yes
  • Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
  • Tag & Nacht-Umschaltung Day,Night,Auto,Schedule
  • Wide Dynamic Range (WDR) 130 dB
  • SNR ≥ 52 dB
  • Bildverbesserung BLC,HLC,3D DNR
  • Privatzone 4 regions of privacy mask
  • Schnittstelle
  • Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Audio 1 input (line in), 2-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 2-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarm 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A)
  • Reset Key Yes
  • Ereignis
  • Normales Ereignis Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error
  • Intelligentes Ereignis Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), Scene change detection
  • Linkage Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,trigger alarm output,white light flashing
  • Deep Learning Function
  • Gesichtserfassung Yes
  • Allgemein
  • Power 12 VDC ± 25%, 1.21 A, max. 14.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3at, Class 4, 42.5 V to 57V, 0.43 A to 0.32 A, max. 18 W
  • Abmessung 298 mm × 97.9 mm × 95.7 mm (11.7" × 3.9" × 3.8")
  • Paketgröße 385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1")
  • Approx. 1465 g (3.2 lb.)
  • Mit Paketgewicht Approx. 2097 g (4.6 lb.)
  • Lagerbedingungen -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Anlauf- und Betriebsbedingungen -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Sprache 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • Allgemeine Funktion Heartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter
  • Genehmigung
  • EMV FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
  • Sicherheit UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, LOA: IEC/EN 60950-1
  • Umgebung CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
  • Schutz IP67: IEC 60529-2013,IK10: IEC 62262:2002
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Spezifikation

Kamera
Bildsensor
1/1.8" Progressive Scan CMOS
Max. Auflösung
2688 × 1520
Min. Beleuchtung
Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Verschlusszeit
1/3 s to 1/100,000 s
Ausrichtungseinstellung
Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°
Tag & Nacht
24/7 color imaging
Objektiv
Objektivtyp
Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV
2.8 to 12 mm, horizontal FOV 105.4° to 56.4°, vertical FOV 53.9° to 31.6°, diagonal FOV 131.8° to 65.1°
Objektivfassung
Integrated
Fokus
Auto,Semi-auto,Manual
Iris Type
DC iris
Blende
F1.0
Depth of Field
1.9 m to ∞
DORI
DORI
D: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m
Strahler
Zusatzbeleuchtung
White Light
Reichweite Zusatzbeleuchtung
Up to 60 m
Intelligente Zusatzbeleuchtung
Yes
Video
Hauptstrom
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
3. Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Videokompression
Main stream: H.265/H.264/H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
Audiokomprimierung
32 Kbps to 8 Mbps
H.264 Typ
Baseline Profile,Main Profile,High Profile
H.265 Typ
Main Profile
Bitratensteuerung
CBR,VBR
Skalierbare Videocodierung (SVC)
H.264 and H.265 encoding
Region of Interest (ROI)
1 fixed region(s) for main stream and sub-stream
Audio
Audiokomprimierung
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bitrate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio-Abtastrate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Umgebungsgeräuschfilterung
Yes
Netzwerk
Protokolle
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Gleichzeitige Live-Ansicht
