8MP ANPR Varifocal Anti-Corrosion Bullet Camera

  • High quality imaging with 8 MP resolution
  • Excellent low-light performance via DarkFighter technology
  • Clear imaging against strong back light due to 120 dB WDR technology
  • License Plate Recognition
  • Efficient H.265+ compression technology to save bandwidth and storage
  • 5 streams to meet a wide variety of applications
  • Water and dust resistant (IP67)
  • 316L stainless steel enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras
  • A built-in wiper(-R) removes water and dust on the screen and ensures clear images when the camera is used in dusty or damp environments

View Less
View more

Available models:

DS-2XC6686G0/P-IZHRS(2.8-12mm)
DS-2XC6686G0/P-IZHRS(8-32mm)

Spezifikation

  • Kamera
  • Bildsensor1/1.8" Progressive Scan CMOS
  • Max. Auflösung3840 × 2160
  • Min. BeleuchtungColor: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
  • Verschlusszeit1 s to 1/100,000 s
  • Tag & NachtIR cut filter Blue glass module to reduce ghost phenomenon
  • Objektiv
  • Focal Length & FOV2.8 to 12 mm, horizontal FOV 100.8° to 40.2°, vertical FOV 53.3° to 22.5°, diagnol FOV 122.3° to 46.2° 8 to 32 mm, horizonral FOV 40.7° to 14.6°, vertical FOV 22.3° to 8.3°, diagnol FOV 47.4° to 16.7°
  • FokusAuto, semi-auto, manual
  • Blende2.8 to 12 mm: F1.38 to F2.5 8 to 32 mm: F1.7
  • DORI
  • DORIWide: 2.8 to 12 mm: D: 87 m, O: 34.5 m, R: 17.4 m, I: 8.7 m 8 to 32 mm: D: 200 m, O: 79.4 m, R: 40m, I: 20 m Tele: 2.8 to 12 mm: D: 216 m, O: 85.7 m, R: 43.2 m, I: 21.6 m 8 to 32 mm: D: 580 m, O: 230 m, R: 116 m, I: 58 m
  • Strahler
  • ZusatzbeleuchtungIR
  • Reichweite Zusatzbeleuchtung2.8 to 12 mm: 60 m 8 to 32 mm: 100 m
  • Intelligente ZusatzbeleuchtungYes
  • IR Wavelength850 nm
  • Video
  • Hauptstrom50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720) 60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720)
  • Sub-Stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
  • 3. Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
  • 4. Stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
  • 5. Stream50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
  • Videokompression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG Third stream: H.265/H.264
  • Audiokomprimierung32 Kbps to 16 Mbps
  • H.264 TypBaseline Profile/Main Profile/High Profile
  • H.265 TypMain Profile
  • BitratensteuerungCBR/VBR
  • Skalierbare Videocodierung (SVC)H.265 and H.264 encoding
  • Region of Interest (ROI)5 fixed regions for each stream
  • Target CroppingYes
  • Audio
  • AudiotypMono sound
  • Audiokomprimierung G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
  • Audio Bitrate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
  • Audio-Abtastrate8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
  • UmgebungsgeräuschfilterungYes
  • Netzwerk
  • ProtokolleTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
  • Gleichzeitige Live-AnsichtUp to 20 channels
  • APIOpen Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
  • Benutzer / HostUp to 32 users. 3 user levels: administrator, operator and user
  • SicherheitPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
  • Netzwerk-SpeicherungNAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • ClientiVMS-4200, Hik-Connect, Hik-Central
  • WebbrowserPlug-in required live view: IE10, IE11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari12+ Local service: Chrome 57.0+, Firefox 52.0+
  • Bild
  • Bildparameter wechselnYes
  • Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
  • Tag & Nacht-UmschaltungDay, Night, Auto, Schedule, Alarm Trigger, Video Trigger
  • Wide Dynamic Range (WDR)120 dB
  • SNR≥ 52 dB
  • BildverbesserungBLC, HLC, Defog, 3D DNR
  • BildüberlagerungLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
  • Image StabilizationEIS
  • Schnittstelle
  • Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
  • Audio1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarm 1 input, 1 output (max. 24 VDC, 1 A or max. 110 VAC, 500 mA)
  • RS-485Without -R: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) -R: does not support
  • Reset KeyYes
  • Wiegand/P: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit)
  • Ereignis
  • Normales Ereignis Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection
  • Intelligentes EreignisLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)) Scene change detection, audio exception detection, defocus detection
  • LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning
  • Deep Learning Function
  • Straßenverkehr und FahrzeugerkennungBlocklist and allowlist: up to 10,000 records Captures vehicle that has no license plate Support license plate recognition of motorcycles (only in checkpoint scenario) Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)
  • MetadatenMetadata of road traffic is supported.
  • Allgemein
  • Power12 VDC ± 20%, 1.8 A, max. 22 W, three-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.5 A to 0. 4 A, max. 22 W
  • Material316L and anti-corrosion coating
  • AbmessungWith -R: 240.8 mm × 145 mm × 166.6 mm (9.5" × 5.7" × 6.6") Without -R: 224 mm × 145 mm × 143.5 mm (8.8" × 5.7" × 5.6")
  • Paketgröße477 mm × 235 mm × 302 mm (18.7" × 9.3" × 11.9")
  • With -R: approx. 4245 g (9.4 lb.) Without -R: approx. 3680 g (8.1 lb.)
  • Mit PaketgewichtWith -R: approx. 5690 g (12.5 lb.) Without -R: approx.4700 g (10.4 lb.)
  • Lagerbedingungen-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Anlauf- und Betriebsbedingungen-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Sprache33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • Allgemeine FunktionAnti-banding, 5 streams, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
  • HeizungYes
  • Wischer-R: Yes
  • Genehmigung
  • EMVFCC: 47 CFR Part 15, Subpart B CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7 KC: KN 32: 2015, KN 35: 2015
  • SicherheitUL: UL 62368-1 CB: IEC 62368-1:2014+A11 CE-LVD: EN 62368-1:2014/A11:2017 BIS: IS 13252(Part 1):2010/ IEC 60950-1 : 2005 LOA: IEC/EN 60950-1
  • UmgebungCE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006
  • SchutzIP67: IEC 60529-2013 IK10: IEC 62262: 2002 (without -R)
  • KorrosionsschutzNEMA 4X: NEMA 250-2018 C5-M: 720H neutral salt spray, 480H water condensation; Exterior environments: industrial areas with high humidity and aggressive atmosphere and coastal areas with high salinity; Interior environments: buildings or areas with almost permanent condensation and with high pollution.
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Spezifikation

Kamera
Bildsensor
1/1.8" Progressive Scan CMOS
Max. Auflösung
3840 × 2160
Min. Beleuchtung
Color: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Verschlusszeit
1 s to 1/100,000 s
Tag & Nacht
IR cut filter Blue glass module to reduce ghost phenomenon
Objektiv
Focal Length & FOV
2.8 to 12 mm, horizontal FOV 100.8° to 40.2°, vertical FOV 53.3° to 22.5°, diagnol FOV 122.3° to 46.2° 8 to 32 mm, horizonral FOV 40.7° to 14.6°, vertical FOV 22.3° to 8.3°, diagnol FOV 47.4° to 16.7°
Fokus
Auto, semi-auto, manual
Blende
2.8 to 12 mm: F1.38 to F2.5 8 to 32 mm: F1.7
DORI
DORI
Wide: 2.8 to 12 mm: D: 87 m, O: 34.5 m, R: 17.4 m, I: 8.7 m 8 to 32 mm: D: 200 m, O: 79.4 m, R: 40m, I: 20 m Tele: 2.8 to 12 mm: D: 216 m, O: 85.7 m, R: 43.2 m, I: 21.6 m 8 to 32 mm: D: 580 m, O: 230 m, R: 116 m, I: 58 m
Strahler
Zusatzbeleuchtung
IR
Reichweite Zusatzbeleuchtung
2.8 to 12 mm: 60 m 8 to 32 mm: 100 m
Intelligente Zusatzbeleuchtung
Yes
IR Wavelength
850 nm
Video
Hauptstrom
50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720) 60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
3. Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
4. Stream
50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
5. Stream
50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Videokompression
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Audiokomprimierung
32 Kbps to 16 Mbps
H.264 Typ
Baseline Profile/Main Profile/High Profile
H.265 Typ
Main Profile
Bitratensteuerung
CBR/VBR
Skalierbare Videocodierung (SVC)
H.265 and H.264 encoding
Region of Interest (ROI)
5 fixed regions for each stream
Target Cropping
Yes
Audio
Audiotyp
Mono sound
Audiokomprimierung
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Audio Bitrate
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
Audio-Abtastrate
8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
Umgebungsgeräuschfilterung
Yes
Netzwerk
Protokolle
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Gleichzeitige Live-Ansicht
Up to 20 channels
API
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Benutzer / Host
Up to 32 users. 3 user levels: administrator, operator and user
Sicherheit
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Netzwerk-Speicherung
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client
iVMS-4200, Hik-Connect, Hik-Central
Webbrowser
Plug-in required live v
