EXIR Motorized Varifocal Bullet Anti-Corrosion Network Camera

  • 316L stainless steel enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras
  • A built-in wiper removes water and dust on the screen and ensures clear images when the camera is used in dusty or damp environments
  • IP67 water resistant, preventing water ingress for outdoor use
  • H.265+/H.265/H.264+/H.264 encoding: efficient compression technology saves storage space and reduces bandwidth requirements

Spezifikation
  • Kamera
  • Bildsensor1/1.8″ Progressive Scan CMOS
  • Min. BeleuchtungColor: 0.0005 Lux @(F1.2, AGC ON) B/W: 0.0001 Lux @(F1.2, AGC ON), 0 Lux with IR
  • Verschlusszeit1 s to 1/100,000 s
  • Slow ShutterYes
  • DNR3D DNR
  • WDR120dB
  • Tag & NachtIR cut filter
  • Objektiv2.8 – 12 mm, F1.4: horizontal field of view, 94.2° to 38.1° 8 – 32 mm, F1.4: horizontal field of view, 42.2° to 15.1° Motorized zooming and auto focus
  • Auto-IrisDC drive
  • Audio
  • Audio-Abtastrate16kHz/32kHz/44.1kHz/48kHz
  • Audio E/AYes
  • Bild
  • BildverbesserungBLC/HLC/3D DNR/Defog/EIS
  • Target CroppingYes
  • BildüberlagerungLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
  • Image SettingsRotate mode, saturation, brightness, contrast, etc., adjustable by client software or web browser
  • Sub-Stream50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
  • DefogYes
  • EISYes
  • Highlight CompensationYes
  • Day / Night modeYes
  • Max. Auflösung2688 × 1520
  • Hauptstrom50 Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
  • 3. Stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
  • Region of Interest (ROI)Support 4 customized region for each stream
  • Netzwerk
  • AlarmauslöserMotion detection, tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
  • Schnittstelle
  • Kommunikationsschnittstelle1 RJ45 10M/100M self-adaptive Ethernet port
  • Alarm1 input, 1 output
  • Video-Ausgang1Vp-p composite output (75 Ω/BNC)
  • On Board SpeicherBuilt-in microSD/SDHC/SDXC slot, up to 256 G
  • Housing interface2 anti-corrosion inlets protected by a metal hose
  • Genehmigung
  • EMV47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
  • SicherheitUL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
  • Chemie2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
  • Kompressions-Standard
  • H.264+Yes
  • H.265+Yes
  • H.264 TypBaseline profile/main profile/high profile
  • Video-KomprimierungMain stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
  • H.265 TypMain Profile
  • Audio-KomprimierungG.711/G.722.1/G.726/MP2L2/PCM
  • Audiokomprimierung32 Kbps to 16 Mbps
  • Audio Bitrate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
  • IR
  • IR-Reichweite2.8~12mm: 80m, 8~32mm: 150m
  • IR Wavelength850nm
  • Smart Feature-Set
  • AusnahmeerkennungScene change detection, defocus detection, audio exception detection
  • VerhaltensanalyseLine crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
  • Allgemein
  • SpannungsversorgungAC: 24V±20%; PoE: 802.3 at
  • Gewicht10.95 kg (24.14 lb.)
  • LeistungsaufnahmeAC24V: 24V~, 1.7A, 50/60Hz, 40W PoE: (802.3at, 42.5V-57V), 0.57 A to 0.43 A, max: 24W
  • Schutz vor EindringlingenIP67
  • HeizungYes
  • WischerYes
  • Anti-KorrosionNEMA 4X C5-M: 720H neutral salt spray, 480H water condensation; Exterior environments: industrial areas with high humidity and aggressive atmosphere and coastal areas with high salinity; Interior environments: buildings or areas with almost permanent condensation and with high pollution.
