4-ch 5 MP 1U H.265 AcuSense DVR

  • 4 channels and 1 HDD 1U AcuSense DVR
  • Support 2-ch Facial Recognition or 4-ch advanced model Perimeter Protection based on Deep Learning algorithm
  • Support 4-ch AcuSearch Technology
  • Encoding ability up to 4K/8MP @ 8fps(1-ch); 3K/5MP @12fps
  • Up to 8 channels IP camera inputs, each channel up to 8MP
  • 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
  • Support All channels Motion Detection Technology
  • Support All channels HDTVI Two-Way Audio Technology

View Less
View more
Data Sheet
Sales Inquiry

Available models:

iDS-7204HUHI-M1/XT
iDS-7204HUHI-M1/XT
iDS-7204HUHI-M1/XT
NEW
Data Sheet

Specifikace

  • Facial Recognition
  • Knihovna obrazů obličejeUp to 16 face picture libraries
  • Srovnání obrazu obličejeFace picture comparison, face picture search; 2-ch face picture comparison alarm (HD analog camera)
  • Ochrana perimetru
  • Human/Vehicle AnalysisUp to 4-ch
  • Video and Audio
  • IP Video Input4-ch (up to 8-ch), each up to 8 MP
  • Analogový video vstup4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • HDMI Output1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
  • VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
  • CVBS InputPAL/NTSC
  • CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
  • Synchronous Playback4-ch
  • HDTVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • HDCVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • Audio výstup1-ch, RCA (Linear, 1 KΩ)
  • Zvukový vstup1-ch, RCA (2.0 Vp-p, 1 KΩ)，4-ch via coaxial cable
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
  • Recording
  • Video kompreseH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Rozlišení kódováníMain stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4. Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)
  • Video Bitrate32 Kbps to 10 Mbps
  • Dual-streamSupport main stream or sub stream
  • Typ streamuVideo, Video & Audio
  • Audio kompreseG.711u
  • Audio Bitrate64 Kbps
  • Síť
  • Total Bandwidth96 Mbps
  • Síťový protokolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
  • Vzdálené připojení32
  • Síťové rozhraní1, RJ45 10/100 Mbps self-adaptive Ethernet interface
  • Auxiliary Interface
  • SATA1 SATA interface
  • Kapacitaup to 10 TB capacity for each disk
  • Sériové rozhraníRS-485 (half-duplex)
  • USB rozhraníFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
  • Vstup/výstup alarmuN/A
  • Všeobecné
  • Zdroj napájení12 VDC, 1.5 A
  • Spotřeba≤ 10 W
  • Pracovní teplota-10 °C to 55 °C (14 °F to 131 °F)
  • Pracovní vlhkost10% to 90%
  • Rozměry (Š × H × V)319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
  • Váha≤ 1.16 kg (2.6 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specifikace

Facial Recognition
Knihovna obrazů obličeje
Up to 16 face picture libraries
Srovnání obrazu obličeje
Face picture comparison, face picture search; 2-ch face picture comparison alarm (HD analog camera)
Ochrana perimetru
Human/Vehicle Analysis
Up to 4-ch
Video and Audio
IP Video Input
4-ch (up to 8-ch), each up to 8 MP
Analogový video vstup
4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output
1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
CVBS Input
PAL/NTSC
CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Synchronous Playback
4-ch
HDTVI Input
8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
AHD Input
5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
HDCVI Input
8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
Audio výstup
1-ch, RCA (Linear, 1 KΩ)
Zvukový vstup
1-ch, RCA (2.0 Vp-p, 1 KΩ)，4-ch via coaxial cable
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Recording
Video komprese
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Rozlišení kódování
Main stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4. Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)
Video Bitrate
32 Kbps to 10 Mbps
Dual-stream
Support main stream or sub stream
Typ streamu
Video, Video & Audio
Audio komprese
G.711u
Audio Bitrate
64 Kbps
Síť
Total Bandwidth
96 Mbps
Síťový protokol
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Vzdálené připojení
32
Síťové rozhraní
1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA
1 SATA interface
Kapacita
up to 10 TB capacity for each disk
Sériové rozhraní
RS-485 (half-duplex)
USB rozhraní
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Vstup/výstup alarmu
N/A
Všeobecné
Zdroj napájení
12 VDC, 1.5 A
Spotřeba
≤ 10 W
Pracovní teplota
-10 °C to 55 °C (14 °F to 131 °F)
Pracovní vlhkost
10% to 90%
Rozměry (Š × H × V)
319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
Váha
≤ 1.16 kg (2.6 lb)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
Specifikace
Facial Recognition
  • Knihovna obrazů obličejeUp to 16 face picture libraries
  • Srovnání obrazu obličejeFace picture comparison, face picture search; 2-ch face picture comparison alarm (HD analog camera)
Ochrana perimetru
  • Human/Vehicle AnalysisUp to 4-ch
Video and Audio
  • IP Video Input4-ch (up to 8-ch), each up to 8 MP
  • Analogový video vstup4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • HDMI Output1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
  • VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
  • CVBS InputPAL/NTSC
  • CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
  • Synchronous Playback4-ch
  • HDTVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • HDCVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • Audio výstup1-ch, RCA (Linear, 1 KΩ)
  • Zvukový vstup1-ch, RCA (2.0 Vp-p, 1 KΩ)，4-ch via coaxial cable
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Recording
  • Video kompreseH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Rozlišení kódováníMain stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4. Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)
  • Video Bitrate32 Kbps to 10 Mbps
  • Dual-streamSupport main stream or sub stream
  • Typ streamuVideo, Video & Audio
  • Audio kompreseG.711u
  • Audio Bitrate64 Kbps
Síť
  • Total Bandwidth96 Mbps
  • Síťový protokolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
  • Vzdálené připojení32
  • Síťové rozhraní1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
  • SATA1 SATA interface
  • Kapacitaup to 10 TB capacity for each disk
  • Sériové rozhraníRS-485 (half-duplex)
  • USB rozhraníFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
  • Vstup/výstup alarmuN/A
Všeobecné
  • Zdroj napájení12 VDC, 1.5 A
  • Spotřeba≤ 10 W
  • Pracovní teplota-10 °C to 55 °C (14 °F to 131 °F)
  • Pracovní vlhkost10% to 90%
  • Rozměry (Š × H × V)319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
  • Váha≤ 1.16 kg (2.6 lb)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Resources

For better user experience, we highly recommend you to update your device to the latest firmware asap.
Firmware_Asia_V4.83.502_241204
Firmware_Europe_V4.83.502_241204
Turbo HD DVR V4.83.502build241204 Release Notes
