DS-2TD4228T-10/W

Thermographic Thermal & Optical Bi-spectrum Network Speed Dome

Behavior analysis function, based on deep learning algorithm: line crossing, intrusion, region entrance and exit
Temperature exception alarm for fire prevention
Fire detection algorithm
256 × 192 (the resolution of output image is 1280 × 720) resolution, 12 μm, VOx UFPA, NETD ≤ 35 mK (25 °C, F# = 1.0)
Image processing technology: Liner, histogram, and self-adaptive thermal AGC mode, DDE, 3D DNR
High quality detector with 10 years warranty
Smart tracking: Panorama tracking, Event tracking and Multi-scene patrol tracking
Smart tracking linkage: thermal view and optical view
Smoke detection for fire prevention

View Less

Available models:

DS-2TD4228T-10/W

Tepelný modul
Senzor obrazuVanadium Oxide Uncooled Focal Plane Arrays
Řešení256 × 192 (the resolution of output image is 1280 × 720)
Interval pixelů12 μm
Vlna pásma odezvy8 μm to 14 μm
NETDLess than 35 mK (@25 °C,F#=1.0)
Ohnisková vzdálenost10 mm
Režim ostřeníAthermalized
IFOV1.20 mrad
ClonaF1.0
Zorné pole18° × 13.5° (H × V)
Min. Zaostřovací vzdálenost1.2m

Optický modul
Senzor obrazu1/2.8" Progressive Scan CMOS
Řešení2688 × 1520, 4 MP
Min. osvětleníColor: 0.05 Lux @(F1.2，AGC ON), B/W: 0.01 Lux @(F1.2，AGC ON)
Zorné pole58.4° × 33.8° (H × V) to 2.14° × 1.2° (H × V)
Ohnisková vzdálenost4.8-153 mm, 32x
Aperture (Range)F1.2-F4.4
Režim ostřeníAuto/Semi-auto/Manual
Digitální Zoom×2, ×4, ×8, ×16
Rychlost závěrky1s to 1/100,000s
WDR120 dB
Optické odmlžováníNo, support algorithmic defog

Image Effect
Obraz v obrazeDisplay partial image of thermal channel on the full screen of optical channel
Target ColorationSupported in white hot and black hot mode.

PTZ
Rozsah pohybuPan: 360° Continuous Rotate; Tilt: From -5° to + 90° (auto flip)
Rychlost otáčeníConfigurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s
Rychlost náklonuConfigurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s
Proporcionální zvětšeníYes
Předvolby300 in total, 273 are configurable.
Patrolové skenování8; Up to 32 Presets Per Patrol
Vzorové skenování4; More Than 10 Minutes Per Pattern
Vypnutí pamětiYes
ParkováníPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
Stav PTTurn On/Turn Off
Naplánovaný úkolPreset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Iluminátor
IR vzdálenostUp to 100m
IR intenzita a úhelAutomatically adjusted

Inteligentní funkce
VCASupport 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
Měření teplotySupport 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)
Teplotní rozsah-20 °C to 550 °C (-4 °F to 1022 °F)
Přesnost teplotyMax (±2 °C, ±2 %)
Detekce požáruDynamic fire detection, up to 10 fire points detectable.

Video and Audio
Hlavní proudOptical channel 50 Hz:25 fps (1920×1080, 1280×960, 1280×720) 60 Hz:30 fps (1920×1080, 1280×960, 1280×720) Thermal channel 25 fps (1280×720, 704 × 576, 352 × 288, 384 × 288，256 × 192)
Sub-streamOptical channel 50 Hz:25 fps (704 × 576, 352 × 288，256 × 192) 60 Hz:30 fps (704 × 576, 352 × 288) Thermal channel 25 fps (704 × 576, 384 × 288, 352 × 288)
Video kompreseMain stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG
Audio kompreseG .711u/G.711a/G.722.1/MP2L2/G.726/PCM

Síť
ProtokolyIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Síťové úložištěMicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
APIISAPI, HIKVISION SDK, third-party management platform, ONVIF profile S,T,G
Současný živý náhledUp to 20 channels
Úroveň uživatele/hostiteleUp to 32 users, 3 levels: Administrator, Operator, User
BezpečnostUser authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
KlientiVMS-4200, Hik-Connect
Webový prohlížečLive view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Rozhraní
Vstup alarmu7-ch inputs (0-5 VDC)
Výstup alarmu2-ch relay outputs, alarm response actions configurable
Akce alarmuPreset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Zvukový vstup1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio výstupLinear Level; Impedance: 600 Ω
Komunikační rozhraní1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface
Analogový video výstup1.0 V [p-p]/75 Ω, BNC for thermal channel

Všeobecné
Jazyk webového klienta32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Zdroj napájeníAC24±20%、DC36±20%、DC48±20%，HIPOE
Spotřeba energie30W max
Working Temperature/HumidityFrom -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less
Úroveň ochranyIP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Rozměry305 mm × 185 mm × 163 mm (12.01 " × 7.28 " × 6.42 ")
VáhaApprox. 3.9Kg (8.6lb)

Specifikace

Tepelný modul

Senzor obrazu

Vanadium Oxide Uncooled Focal Plane Arrays

Řešení

256 × 192 (the resolution of output image is 1280 × 720)

Interval pixelů

12 μm

Vlna pásma odezvy

8 μm to 14 μm

NETD

Less than 35 mK (@25 °C,F#=1.0)

Ohnisková vzdálenost

10 mm

Režim ostření

Athermalized

IFOV

1.20 mrad

Clona

F1.0

Zorné pole

18° × 13.5° (H × V)

Min. Zaostřovací vzdálenost

1.2m

Optický modul

Senzor obrazu

1/2.8" Progressive Scan CMOS

Řešení

2688 × 1520, 4 MP

Min. osvětlení

Color: 0.05 Lux @(F1.2，AGC ON), B/W: 0.01 Lux @(F1.2，AGC ON)

Zorné pole

58.4° × 33.8° (H × V) to 2.14° × 1.2° (H × V)

Ohnisková vzdálenost

4.8-153 mm, 32x

Aperture (Range)

F1.2-F4.4

Režim ostření

Auto/Semi-auto/Manual

Digitální Zoom

×2, ×4, ×8, ×16

Rychlost závěrky

1s to 1/100,000s

WDR

120 dB

Optické odmlžování

No, support algorithmic defog

Image Effect

Obraz v obraze

Display partial image of thermal channel on the full screen of optical channel

Target Coloration

Supported in white hot and black hot mode.

PTZ

Rozsah pohybu

Pan: 360° Continuous Rotate; Tilt: From -5° to + 90° (auto flip)

Rychlost otáčení

Configurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s

Rychlost náklonu

Configurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s

Proporcionální zvětšení

Yes

Předvolby

300 in total, 273 are configurable.

Patrolové skenování

8; Up to 32 Presets Per Patrol

Vzorové skenování

4; More Than 10 Minutes Per Pattern

Vypnutí paměti

Yes

Parkování

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan

Stav PT

Turn On/Turn Off

Naplánovaný úkol

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output

Iluminátor

IR vzdálenost

Up to 100m

IR intenzita a úhel

Automatically adjusted

Inteligentní funkce

VCA

Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene

Měření teploty

Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)

Teplotní rozsah

-20 °C to 550 °C (-4 °F to 1022 °F)

Přesnost teploty

Max (±2 °C, ±2 %)

Detekce požáru

Dynamic fire detection, up to 10 fire points detectable.

Video and Audio

Hlavní proud

Optical channel 50 Hz:25 fps (1920×1080, 1280×960, 1280×720) 60 Hz:30 fps (1920×1080, 1280×960, 1280×720) Thermal channel 25 fps (1280×720, 704 × 576, 352 × 288, 384 × 288，256 × 192)

Sub-stream

Optical channel 50 Hz:25 fps (704 × 576, 352 × 288，256 × 192) 60 Hz:30 fps (704 × 576, 352 × 288) Thermal channel 25 fps (704 × 576, 384 × 288, 352 × 288)

Video komprese

Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG

Audio komprese

G .711u/G.711a/G.722.1/MP2L2/G.726/PCM

Síť

Protokoly

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Síťové úložiště

MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

API

ISAPI, HIKVISION SDK, third-party management platform, ONVIF profile S,T,G

Současný živý náhled

Up to 20 channels

Úroveň uživatele/hostitele

Up to 32 users, 3 levels: Administrator, Operator, User

Bezpečnost

User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering

Klient

iVMS-4200, Hik-Connect

Webový prohlížeč

Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 +

Rozhraní

Vstup alarmu

7-ch inputs (0-5 VDC)

Výstup alarmu

2-ch relay outputs, alarm response actions configurable

Akce alarmu

Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage

Zvukový vstup

1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%

Audio výstup

Linear Level; Impedance: 600 Ω

Komunikační rozhraní

1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface

Analogový video výstup

1.0 V [p-p]/75 Ω, BNC for thermal channel

Všeobecné

Jazyk webového klienta

32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Zdroj napájení

AC24±20%、DC36±20%、DC48±20%，HIPOE

Spotřeba energie

30W max

Working Temperature/Humidity

From -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less

Úroveň ochrany

IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Rozměry

305 mm × 185 mm × 163 mm (12.01 " × 7.28 " × 6.42 ")

Váha

Approx. 3.9Kg (8.6lb)
