DS-2DF8C435MHS-DEL

8-inch 4 MP 35X DarkFighterX IR Network Speed Dome

Dual sensor 1/1.8" progressive scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with DarkFighterX technology
35 × optical zoom and 16 × digital zoom provide close up views over expansive areas
300 m IR distance
Water and dust resistant (IP67) and vandal resistant (IK10) excluding glass window
Supports face capture to detect, capture, grade, and select faces in motion
Supports road traffic to detect vehicles
Efficient H.265+/H.265 compression technology
140 dB WDR, 3D DNR, HLC, BLC, EIS, defog

View Less

Available models:

DS-2DF8C435MHS-DEL

Kamera
Senzor obrazuTwo sensors, 1/1.8" Progressive Scan CMOS
Max. rozlišení2560 × 1440
Min. osvětleníColor: 0.0004 Lux @ (F1.6, AGC ON),B/W: 0.0001 Lux @ (F1.6, AGC ON),0 Lux with IR
Rychlost závěrky1/1 s to 1/30000 s
Zoom35 × optical,16 × digital
Pomalá závěrkaYes
BLCyes
3D DNRyes

Objektiv
Ohnisková vzdálenost5.9 to 206.5 mm
FOVHorizontal field of view: 60.2° to 2.24°, vertical field of view: 36° to 1.26°, diagonal field of view: 68° to 2.56°
OhniskoAuto,semi-auto,manual
ClonaMax. F1.6
Rychlost zoomuApprox. 4.3 s

PTZ
Rozsah pohybu (otáčení)360° endless
Rozsah pohybu (náklon)-20° to 90°,auto flip
Rychlost otáčeníPan speed: configurable from 0.1° to 210°/s, preset speed: 280°/s
Rychlost náklonuTilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
Proportional PanYes
Předvolby300
Přednastavené zmrazeníYes
Patrolové skenování8 patrols, up to 32 presets for each patrol
Vzorové skenování4 pattern scans, record time over 10 minutes for each scan
ParkováníPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan
3D polohováníYes
Zobrazení stavu PTZYes
Naplánovaný úkolPreset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,dome reboot,dome adjust,aux output,panorama scan
Vypínací paměťYes

Video
Hlavní proud50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Vedlejší stream50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Třetí proud50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video kompreseMain stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Přenosová rychlost videa32 Kbps to 16 Mbps
H.264 typBaseline profile,Main profile,High profile
H.265 typMain profile
Škálovatelné kódování videa (SVC)H.264 and H.265 encoding
Oblast zájmu (ROI)8 fixed regions for each stream

Zvuk
Audio kompreseG.711,G.722.1,G.726,MP2L2,PCM,AAC-LC
Přenosová rychlost zvuku64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC)

Síť
ProtokolyTCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour
Současný živý náhledUp to 20 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Uživatel/hostitelUp to 32 users. 3 user levels: administrator, operator, and user
BezpečnostPassword protection,complicated password,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,IP address filter,basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,control timeout settings,security audit log,TLS 1.3,host authentication (MAC address)
Síťové úložištěNAS (NFS, SMB/CIFS),auto network replenishment (ANR)
KlientiVMS-4200,HikCentral Pro,Hik-Connect
Webový prohlížečSafari12+,Chrome57+,Firefox52+,IE10+

Obraz
Přepínač parametrů obrazuYes
Nastavení obrazuSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Přepínač den/nocDay,night,auto,schedule
Wide Dynamic Range (WDR)140 dB
SNR≥ 52 dB
DefogOptical defog
Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
Maska ochrany osobních údajů24 programmable polygon privacy masks, mask color or mosaic configurable
Regionální zaměřeníYes
Regionální expoziceYes

Rozhraní
Video výstupCVBS: 1.0 V[p-p]/75 Ω, PAL/NTSC, BNC connector
Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
Vnitřní uložištěBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Zvuk1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
Alarm7 input(s), 2 output(s)
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
ResetovatYes

Událost
Základní událostMotion detection,video tampering alarm,exception,alarm input and output
Inteligentní událostLine crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection,unattended baggage detection,object removal detection
Propojení alarmuUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,and PTZ actions (such as preset, patrol scan, pattern scan)
