DS-2CD3D46G2T-IZMSU

4 MP HDMI Varifocal Dome Network Camera

High quality imaging with 4 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 140 dB WDR technology
Support HD HDMI video output
Excellent low-light performance with DarkFighter technology
False alarm reduction through human and vehicle target classification based on deep learning
Anti-IR Reflection
Audio and alarm interface available
Water and dust resistant (IP67) and vandal-resistant (IK10)

View Less

Available models:

DS-2CD3D46G2T-IZMSU(2.8-12mm)(C)

Kamera
Senzor obrazu1/1.8" Progressive Scan CMOS
Max. rozlišení2688 × 1520
Min. osvětleníColor: 0.0014 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR
Čas závěrky1/3 s to 1/100,000 s
Den & NocIR cut filter
Nastavení úhluPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°

Objektiv
Focal Length & FOV2.8 to 12 mm, horizontal FOV 115° to 42°, vertical FOV 59° to 24°, diagonal FOV 141° to 48°
Držák objektivuIntegrated
Iris TypeP-iris
ClonaF1.2
Depth of Field2.8 to 12 mm: 1.5 m to ∞

DORI
DORI2.8 to 12 mm: D: 60 m to 149 m, O: 23 m to 59 m, R: 12 m to 29 m, I: 6 m to 14 m

Iluminátor
Doplňte rozsah světlaUp to 40 m
Doplňkový typ světlaIR
Chytré doplňkové světloYes
IR Wavelength850 nm

Video
Hlavní proud50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Vedlejší stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Třetí proud50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), *Third stream is supported under certain settings.
Čtvrtý proud 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360), *Fourth stream is supported under certain settings.
Video kompreseMain stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, *Third stream and fourth stream are supported under certain settings.
Přenosová rychlost videa32 Kbps to 8 Mbps
H.264 typBaseline Profile,Main Profile,High Profile
H.265 typMain Profile
Řízení bitové rychlostiCBR,VBR
Škálovatelné kódování videa (SVC)H.264 and H.265 encoding
Oblast zájmu (ROI)5 fixed region(s) for main stream and sub-stream
Oříznutí cíleYes

Zvuk
Typ zvukuMono sound
Audio kompreseG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Přenosová rychlost zvuku64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Míra audio vzorů8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Filtrování šumu prostředíYes

Síť
ProtokolyTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP
Současný živý náhledUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Uživatel/hostitelUp to 32 users 3 user levels: administrator, operator, and user
BezpečnostPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface, memory card encryption, SFTP encryption, SRTP encryption
Síťové úložištěNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
KlientiVMS-4200,Hik-Connect,Hik-Central
Webový prohlížečPlug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+

Obraz
Přepínač parametrů obrazuYes
Nastavení obrazuRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Přepínač den/nocDay,Night,Auto,Schedule
Wide Dynamic Range (WDR)140 dB
Vylepšení obrazuBLC,HLC,3D DNR
SNR≥ 52 dB
Maska ochrany osobních údajů8 programmable polygon privacy masks

Rozhraní
Video výstupHDMI (HDMI 1.4, no adapter included): 1920 × 1080P@25/30/50/60 Hz
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Zvuk1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Zabudovaný mikrofonYes
Alarm 2 inputs, 2 outputs (max. 24 VDC, 1 A; 24 VAC, 1 A)
Reset KeyYes
Výstupní výkon12 VDC, max. 100 mA

Událost
Základní událostMotion detection,video tampering alarm,exception
Inteligentní událostLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), Unattended baggage detection, object removal detection, scene change detection, audio exception detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output,audible warning

Deep Learning Function
Zachycení obličejeYes

Všeobecné
Napájení12 VDC ± 25%, 0.9 A, max. 10.8 W,two-core terminal block,reverse polarity protection, 24 VAC ± 20%, 0.75 A, max. 10.8 W, PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
MateriálMetal
Rozměry Ø162 mm × 141.8 mm (Ø6.4" × 5.6")
Rozměr balení251 mm × 215 mm × 189 mm (9.9" × 8.5" × 7.4")
VáhaApprox. 1420 g (3.1 lb.)
S váhou baleníApprox. 2058 g (4.5 lb.)
Podmínky skladování-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Spuštění a provozní podmínky-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Obecné funkceHeartbeat,anti-flicker,mirror,flash log,password reset via email,pixel counter
Jazyk 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Schválení
EMCFCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
BezpečnostUL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
životní prostředíCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
OchranaIP67: IEC 60529-2013;IK10: IEC 62262:2002

Specifikace

Kamera

Senzor obrazu

1/1.8" Progressive Scan CMOS

Max. rozlišení

2688 × 1520

Min. osvětlení

Color: 0.0014 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR

Čas závěrky

1/3 s to 1/100,000 s

Den & Noc

IR cut filter

Nastavení úhlu

Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°

Objektiv

Focal Length & FOV

2.8 to 12 mm, horizontal FOV 115° to 42°, vertical FOV 59° to 24°, diagonal FOV 141° to 48°

Držák objektivu

Integrated

Iris Type

P-iris

Clona

F1.2

Depth of Field

2.8 to 12 mm: 1.5 m to ∞

DORI

2.8 to 12 mm: D: 60 m to 149 m, O: 23 m to 59 m, R: 12 m to 29 m, I: 6 m to 14 m

Iluminátor

Doplňte rozsah světla

Up to 40 m

Doplňkový typ světla

Chytré doplňkové světlo

Yes

IR Wavelength

850 nm

Video

Hlavní proud

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Vedlejší stream

50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)

Třetí proud

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), *Third stream is supported under certain settings.

Čtvrtý proud

50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360), *Fourth stream is supported under certain settings.

Video komprese

Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, *Third stream and fourth stream are supported under certain settings.

Přenosová rychlost videa

32 Kbps to 8 Mbps

H.264 typ

Baseline Profile,Main Profile,High Profile

H.265 typ

Main Profile

Řízení bitové rychlosti

CBR,VBR

Škálovatelné kódování videa (SVC)

H.264 and H.265 encoding

Oblast zájmu (ROI)

5 fixed region(s) for main stream and sub-stream

Oříznutí cíle

Yes

Zvuk

Typ zvuku

Mono sound

Audio komprese

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Přenosová rychlost zvuku

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

Míra audio vzorů

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Filtrování šumu prostředí

Yes

Síť

Protokoly

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP

Současný živý náhled

Up to 6 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Uživatel/hostitel

Up to 32 users 3 user levels: administrator, operator, and user

Bezpečnost

Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface, memory card encryption, SFTP encryption, SRTP encryption

Síťové úložiště

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Klient

iVMS-4200,Hik-Connect,Hik-Central

Webový prohlížeč

Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+

Obraz

Přepínač parametrů obrazu

Yes

Nastavení obrazu

Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Přepínač den/noc

Day,Night,Auto,Schedule

Wide Dynamic Range (WDR)

140 dB

Vylepšení obrazu

BLC,HLC,3D DNR

SNR

≥ 52 dB

Maska ochrany osobních údajů

8 programmable polygon privacy masks

Rozhraní

Video výstup

HDMI (HDMI 1.4, no adapter included): 1920 × 1080P@25/30/50/60 Hz

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

Zvuk

1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Zabudovaný mikrofon

Yes

Alarm

2 inputs, 2 outputs (max. 24 VDC, 1 A; 24 VAC, 1 A)

Reset Key

Yes

Výstupní výkon

12 VDC, max. 100 mA

Událost

Základní událost

Motion detection,video tampering alarm,exception

Inteligentní událost

Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), Unattended baggage detection, object removal detection, scene change detection, audio exception detection

Linkage

Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output,audible warning

Deep Learning Function

Zachycení obličeje

Yes

Všeobecné

Napájení

12 VDC ± 25%, 0.9 A, max. 10.8 W,two-core terminal block,reverse polarity protection, 24 VAC ± 20%, 0.75 A, max. 10.8 W, PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W

Materiál

Metal

Rozměry

Ø162 mm × 141.8 mm (Ø6.4" × 5.6")

Rozměr balení

251 mm × 215 mm × 189 mm (9.9" × 8.5" × 7.4")

Váha

Approx. 1420 g (3.1 lb.)

S váhou balení

Approx. 2058 g (4.5 lb.)

Podmínky skladování

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Spuštění a provozní podmínky

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Obecné funkce

Heartbeat,anti-flicker,mirror,flash log,password reset via email,pixel counter

Jazyk

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Schválení

EMC

FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015

Bezpečnost

UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

životní prostředí

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
