5 MP AcuSense Varifocal Dome Network Camera

  • High quality imaging with 5 MP resolution
  • Excellent low-light performance with powered-by-DarkFighter technology
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • Efficient H.265+ compression technology
  • Focus on human and vehicle targets classification based on deep learning
  • Water and dust resistant (IP67) and vandal-resistant (IK10)
  • 3D DNR technology delivers clean and sharp images
  • Motorized varifocal lens for easy installation and monitoring

View Less
View more

Available models:

DS-2CD3756G2T-IZS(2.7-13.5mm)(C)
DS-2CD3756G2T-IZS(7-35mm)(C)

Specifikace

  • Kamera
  • Senzor obrazu1/2.7" Progressive Scan CMOS
  • Max. rozlišení2592 × 1944
  • Min. osvětleníColor: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR
  • Čas závěrky1/3 s to 1/100,000 s
  • Den & NocIR cut filter
  • Nastavení úhluPan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
  • Objektiv
  • Typ objektivuVarifocal lens, motor-driven lens, 2.7 to 13.5 mm and 7 to 35 mm optional
  • Focal Length & FOV2.7 to 13.5 mm: horizontal FOV 103° to 32°, vertical FOV 73° to 24°, diagonal FOV 142° to 40° 7 to 35 mm: horizontal FOV 28° to 10°, vertical FOV 21° to 8°, diagonal FOV 35° to 13°
  • Držák objektivu2.7 to 13.5 mm: Ø14 7 to 35 mm: Integrated
  • Iris TypeAuto-iris
  • Clona2.7 to 13.5 mm: F1.4 7 to 35 mm: F1.6
  • DORI
  • DORI2.7 to 13.5 mm: D: 64 to 187 m, O: 25 to 74 m, R: 12 to 37 m, I: 6 to 18 m 7 to 35 mm: D: 200 to 580 m, O: 79 to 230 m, R: 40 to 116 m, I: 20 to 58 m
  • Iluminátor
  • Doplňkový typ světlaIR
  • Doplňte rozsah světla2.7 to 13.5 mm: up to 40 m 7 to 35 mm: up to 50 m
  • Chytré doplňkové světloYes
  • IR Wavelength850 nm
  • Video
  • Hlavní proud50 Hz: 25 fps (2592 × 1944, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2592 × 1944) 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • Vedlejší stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
  • Třetí proud50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
  • Čtvrtý proud50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under certain settings.
  • Video kompreseMain stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG *Third stream and fourth stream are supported under certain settings.
  • Přenosová rychlost videa32 Kbps to 16 Mbps
  • H.264 typBaseline Profile/Main Profile/High Profile
  • H.265 typMain Profile
  • Řízení bitové rychlostiCBR/VBR
  • Škálovatelné kódování videa (SVC)H.264 and H.265 encoding
  • Oblast zájmu (ROI)5 fixed regions for main stream and sub-stream
  • Oříznutí cíleYes
  • Zvuk
  • Audio kompreseG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
  • Přenosová rychlost zvuku64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
  • Míra audio vzorů8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Filtrování šumu prostředíYes
  • Síť
  • ProtokolyTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP
  • Současný živý náhledUp to 6 channels
  • APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
  • Uživatel/hostitelUp to 32 users. 3 user levels: administrator, operator and user
  • BezpečnostPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
  • Síťové úložištěMicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • KlientiVMS-4200, Hik-Connect, Hik-Central
  • Webový prohlížečPlug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
  • Obraz
  • Přepínač parametrů obrazuYes
  • Nastavení obrazuRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
  • Přepínač den/nocDay, Night, Auto, Schedule
  • Wide Dynamic Range (WDR)120 dB
  • SNR≥ 52 dB
  • Vylepšení obrazuBLC, HLC, 3D DNR
  • Rozhraní
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 256 GB
  • Zvuk1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarm 2 inputs, 2 outputs (max. 24 VAC/24 VDC, 1 A)
  • Reset KeyYes
  • Výstupní výkon12 VDC, max. 100 mA
  • Událost
  • Základní událostMotion detection (human and vehicle targets classification), video tampering alarm, exception
  • Inteligentní událostUnattended baggage detection, object removal detection, scene change detection, audio exception detection
  • LinkageUpload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, audible warning
  • Deep Learning Function
  • Zachycení obličejeYes
  • Ochrana perimetruLine crossing detection, intrusion detection, region entrance detection, region exiting detection
  • Všeobecné
  • Napájení12 VDC ± 25%, 0.9 A, max. 10.8 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
  • RozměryØ153.3 mm × 111.6 mm (6.0" × 4.4")
  • Rozměr balení261 mm × 217 mm × 197 mm (10.3" × 8.5" × 7.8")
  • VáhaApprox. 885 g (1.9 lb.)
  • S váhou baleníApprox. 1843 g (3.2 lb.)
