DS-2CD3726G2T-IZS

2 MP AcuSense Varifocal Dome Network Camera

High quality imaging with 2 MP resolution
Excellent low-light performance with powered-by-DarkFighter technology
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
False alarm reduction through human and vehicle target classification based on deep learning
Water and dust resistant (IP67) and vandal-resistant (IK10)
3D DNR technology delivers clean and sharp images
Motorized varifocal lens for easy installation and monitoring

View Less

View more

Available models:

DS-2CD3726G2T-IZS(7-35mm)(C)

Kamera
Senzor obrazu1/2.8" Progressive Scan CMOS
Max. rozlišení1920 × 1080
Min. osvětleníColor: 0.002 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR
Čas závěrky1/3 s to 1/100,000 s
Den & NocIR cut filter
Nastavení úhluPan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°

Objektiv
Typ objektivuVarifocal lens, motor-driven lens, 2.7 to 13.5 mm and 7 to 35 mm optional
Focal Length & FOV2.7 to 13.5 mm: horizontal FOV 113° to 34°, vertical FOV 58° to 19°, diagonal FOV 138° to 39° 7 to 35 mm: horizontal FOV 30° to 11°, vertical FOV 17° to 6°, diagonal FOV 34° to 13°
Držák objektivu2.7 to 13.5 mm: Ø14 7 to 35 mm: Integrated
Iris TypeAuto-iris
Clona2.7 to 13.5 mm: F1.4 7 to 35 mm: F1.6

DORI
DORI2.7 to 13.5 mm: D: 44 to 129 m, O: 17 to 51 m, R: 8 to 25 m, I: 4 to 13 m 7 to 35 mm: D: 137 to 400 m, O: 54 to158 m, R: 27 to 80 m, I: 13 to 40 m

Iluminátor
Doplňkový typ světlaIR
Doplňte rozsah světla2.7 to 13.5 mm: up to 40 m 7 to 35 mm: up to 50 m
Chytré doplňkové světloYes
IR Wavelength850 nm

Video
Hlavní proud50 Hz: up to 50 fps (1920 × 1080, 1280 × 720) 60 Hz: up to 60 fps (1920 × 1080, 1280 × 720) *High frame rate is supported under certain settings.
Vedlejší stream50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Třetí proud50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Čtvrtý proud50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) *Fourth stream is supported under certain settings.
Video kompreseMain stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG *Third stream and fourth stream are supported under certain settings.
Přenosová rychlost videa32 Kbps to 8 Mbps
H.264 typBaseline Profile/Main Profile/High Profile
H.265 typMain Profile
Řízení bitové rychlostiCBR/VBR
Škálovatelné kódování videa (SVC)H.264 and H.265 encoding
Oblast zájmu (ROI)5 fixed regions for main stream and sub-stream
Oříznutí cíleYes

Zvuk
Audio kompreseG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Přenosová rychlost zvuku64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Míra audio vzorů8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Filtrování šumu prostředíYes

Síť
ProtokolyTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP, WebSocket, WebSockets
Současný živý náhledUp to 6 channels
APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Uživatel/hostitelUp to 32 users. 3 user levels: administrator, operator and user
BezpečnostPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Síťové úložištěNAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
KlientiVMS-4200, Hik-Connect, Hik-Central
