DS-2CD3387G2P-LSU/SL

8 MP Panoramic ColorVu Fixed Turret Network Camera

High quality imaging with 8 MP resolution
One image that presents all the scenes covered by the camera
24/7 colorful imaging
Efficient H.265+ compression technology
Clear imaging against strong back light due to 130 dB WDR technology
Focus on human and vehicle classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Water and dust resistant (IP67)

View Less

Available models:

DS-2CD3387G2P-LSU/SL(4mm)(C)

Kamera
Senzor obrazu2 × 1/1.8" Progressive Scan CMOS
Max. rozlišení5120 × 1440
Min. osvětleníColor: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Čas závěrky1/3 s to 1/100,000 s
Nastavení úhluPan: -30° to 30°,tilt: -75° to 75°

Objektiv
Typ objektivuFixed focal lens, dual lens: 4 mm
Focal Length & FOV4 mm, horizontal FOV 180° ± 10°, vertical FOV 44°
Držák objektivuM16
Iris TypeFixed
ClonaF1.0
Depth of Field3.6 m to ∞

DORI
DORI4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m

Iluminátor
Doplňkový typ světlaWhite Light
Doplňte rozsah světlaUp to 40 m
Chytré doplňkové světloYes

Video
Hlavní proudWhen WDR is On: 50 Hz: 12.5 fps (5120 × 1440) 60 Hz: 15 fps (5120 × 1440) When WDR is Off: 50 Hz: 20 fps (5120 × 1440) 60 Hz: 20 fps (5120 × 1440)
Vedlejší streamWhen WDR is On: 50 Hz: 12.5 fps (1920 × 536, 960 × 272) 60 Hz: 15 fps (1920 × 536, 960 × 272) When WDR is Off: 50 Hz: 20 fps (1920 × 536, 960 × 272) 60 Hz: 20 fps (1920 × 536, 960 × 272)
Video kompreseMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
Přenosová rychlost videa32 Kbps to 16 Mbps
H.264 typBaseline Profile,Main Profile,High Profile
H.265 typMain Profile
Řízení bitové rychlostiCBR,VBR
Škálovatelné kódování videa (SVC)H.264 and H.265 encoding
Oblast zájmu (ROI)1 fixed region(s) for main stream

Zvuk
Typ zvukuMono sound
Audio kompreseG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Přenosová rychlost zvuku64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Míra audio vzorů8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Filtrování šumu prostředíYes

Síť
ProtokolyTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Současný živý náhledUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Uživatel/hostitelUp to 32 users 3 user levels: administrator, operator, and user
BezpečnostPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)
Síťové úložištěNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),NVR, Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
KlientiVMS-4200,Hik-Connect,Hik-Central
Webový prohlížečPlug-in required live view: IE 10, IE 11 , Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Obraz
Přepínač parametrů obrazuYes
Nastavení obrazusaturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Přepínač den/nocDay,Night,Auto,Schedule
Wide Dynamic Range (WDR)130 dB
SNR≥ 52 dB
Vylepšení obrazuBLC,HLC,3D DNR

Rozhraní
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512 GB
Zabudovaný mikrofonYes
Vestavěný reproduktorMax. power consumption: 1.2 W, max. sound pressure: 10 cm: 95 dB
Zvuk1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm 1 input, 1 output (max. 24 VDC, 1 A)
Reset KeyYes

Událost
Základní událostMotion detection (support alarm triggering by specified target types (human and vehicle)),alarm input and output,flashing alarm light output, audible alarm output, exception
Inteligentní událostLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection,audio exception detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,white light flashing

Deep Learning Function
Ochrana perimetruLine crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))

Všeobecné
Napájení12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W
MateriálBase: metal, cover: metal
Rozměry Ø155 mm × 155.3 mm (Ø6.1" × 6.1")
Rozměr balení230 mm × 230 mm × 230 mm (9" × 9" × 9")
VáhaApprox. 1110 g (2.4 lb.)
S váhou baleníApprox. 1900 g (4.2 lb.)
Podmínky skladování-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Spuštění a provozní podmínky-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Jazyk33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Obecné funkceAnti-flicker, heartbeat, password reset via email, password protection, one-key reset

Schválení
EMCFCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
BezpečnostUL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
životní prostředíCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
OchranaIP67: IEC 60529-2013

Specifikace

Kamera

Senzor obrazu

2 × 1/1.8" Progressive Scan CMOS

Max. rozlišení

5120 × 1440

Min. osvětlení

Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light

Čas závěrky

1/3 s to 1/100,000 s

Nastavení úhlu

Pan: -30° to 30°,tilt: -75° to 75°

Objektiv

Typ objektivu

Fixed focal lens, dual lens: 4 mm

Focal Length & FOV

4 mm, horizontal FOV 180° ± 10°, vertical FOV 44°

Držák objektivu

M16

Iris Type

Fixed

Clona

F1.0

Depth of Field

3.6 m to ∞

DORI

4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m

Iluminátor

Doplňkový typ světla

White Light

Doplňte rozsah světla

Up to 40 m

Chytré doplňkové světlo

Yes

Video

Hlavní proud

When WDR is On: 50 Hz: 12.5 fps (5120 × 1440) 60 Hz: 15 fps (5120 × 1440) When WDR is Off: 50 Hz: 20 fps (5120 × 1440) 60 Hz: 20 fps (5120 × 1440)

Vedlejší stream

When WDR is On: 50 Hz: 12.5 fps (1920 × 536, 960 × 272) 60 Hz: 15 fps (1920 × 536, 960 × 272) When WDR is Off: 50 Hz: 20 fps (1920 × 536, 960 × 272) 60 Hz: 20 fps (1920 × 536, 960 × 272)

Video komprese

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG

Přenosová rychlost videa

32 Kbps to 16 Mbps

H.264 typ

Baseline Profile,Main Profile,High Profile

H.265 typ

Main Profile

Řízení bitové rychlosti

CBR,VBR

Škálovatelné kódování videa (SVC)

H.264 and H.265 encoding

Oblast zájmu (ROI)

1 fixed region(s) for main stream

Zvuk

Typ zvuku

Mono sound

Audio komprese

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Přenosová rychlost zvuku

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

Míra audio vzorů

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Filtrování šumu prostředí

Yes

Síť

Protokoly

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets

Současný živý náhled

Up to 6 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Uživatel/hostitel

Up to 32 users 3 user levels: administrator, operator, and user

Bezpečnost

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)

Síťové úložiště

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),NVR, Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Klient

iVMS-4200,Hik-Connect,Hik-Central

Webový prohlížeč

Plug-in required live view: IE 10, IE 11 , Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Obraz

Přepínač parametrů obrazu

Yes

Nastavení obrazu

saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Přepínač den/noc

Day,Night,Auto,Schedule

Wide Dynamic Range (WDR)

130 dB

SNR

≥ 52 dB

Vylepšení obrazu

BLC,HLC,3D DNR

Rozhraní

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512 GB

Zabudovaný mikrofon

Yes

Vestavěný reproduktor

Max. power consumption: 1.2 W, max. sound pressure: 10 cm: 95 dB

Zvuk

1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarm

1 input, 1 output (max. 24 VDC, 1 A)

Reset Key

Yes

Událost

Základní událost

Motion detection (support alarm triggering by specified target types (human and vehicle)),alarm input and output,flashing alarm light output, audible alarm output, exception

Inteligentní událost

Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection,audio exception detection

Linkage

Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,white light flashing

Deep Learning Function

Ochrana perimetru

Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))

Všeobecné

Napájení

12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W

Materiál

Base: metal, cover: metal

Rozměry

Ø155 mm × 155.3 mm (Ø6.1" × 6.1")

Rozměr balení

230 mm × 230 mm × 230 mm (9" × 9" × 9")

Váha

Approx. 1110 g (2.4 lb.)

S váhou balení

Approx. 1900 g (4.2 lb.)

Podmínky skladování

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Spuštění a provozní podmínky

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Jazyk

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Obecné funkce

Anti-flicker, heartbeat, password reset via email, password protection, one-key reset

Schválení

EMC

FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7

Bezpečnost

UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017

životní prostředí

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Ochrana

IP67: IEC 60529-2013
